Page 1
2
Precautions
On safety
-Before operating the unit, check that
the operating voltage of your unit is
identical with that of your local
power supply.
-Should any solid object or liquid fall
into the cabinet, unplug the unit and
have it checked by qualified
personnel before operating it any
further.
-Unplug the unit from the wall outlet
if it is not to be used for an extended
period of time. To disconnect the
cord, pull it out by the plug. Never
pull the cord itself.
-The unit is not disconnected from the
AC power source (mains) as long as it
is connected to the wall outlet, ever if
the unit itself has been turned off.
-The nameplate indicating operating
voltage, power consumption, etc. is
located on the rear exterior.
On placement
-Place the unit on a level surface.
-Avoid placing the unit near electrical
appliances (such as a television, hair
dryer, or fluorescent lamp) which
may cause hum or noise.
-Place the unit where it will not be
subject to any vibration, such as from
speakers, slamming of doors, etc.
-Keep the unit away from direct
sunlight, extremes of temperature,
and excessive dust and moisture.
-Use caution when placing the unit on
surfaces that have been specially
treated (with wax, oil, polish, etc.) as
staining or discoloraion of the surface
may result.
On repacking
Keep the carton and packing materials.
They provide an ideal container to
transport the unit.
If you have any question or problem
concerning your unit that is not covered
in this manual, please consult your
nearest Sony dealer.
WARNING
To prevent fire or shock
hazard, do not expose
the unit to rain or
moisture.
For the customers in the
U.S.A.
This symbol is intended to alert the user
to the presence of uninsulated
dangerous voltage within the
products enclosure that may be of
sufficient magnitude to constitute a risk
of electric shock to persons.
This symbol is intended to alert the user
to the presence of important operating
and maintenance (servicing)
instructions in the literature
accompanying the appliance.
CAUTION
You are cautioned that any changes or
modification not expressly approved in
this manual could void your authority
to operate this equipment.Do not install the appliance in a
confined space, such as a bookcase or
built-in cabinet.
For the customers in Canada
CAUTION
TO PREVENT ELECTRIC SHOCK, DO
NOT USE THIS POLARIZED AC PLUG
WITH AN EXTENSION CORD,
RECEPTACLE OR OTHER OUTLET
UNLESS THE BLADES CAN BE FULLY
INSERTED TO PREVENT BLADE
EXPOSURE.
Page 2
3
T ABLE OF CONTENTS
Getting Started
Unpacking 3
Assembling the Turntable 4
Setting the Voltage Selector (Only on models supplied with a
voltage selector) 4
Hooking up the Turntable 5
Operations
Playing a Record 6
Additional Information
Maintenance 7
Troubleshooting 8
Specifications 8
Parts and Controls 9
Welcome!
Thank you for purchasing the Sony
Stereo Turntable System. Before
operating the unit, please read this
manual thoroughly and retain it for
future reference.
Convention
The following icon is used in this
manual:
z Indicates hints and tips for
making the task easier.
Unpacking
Check that you received the following items with your turntable:
-Rubber mat (1)
-45 r/min adaptor (1)
