NW-HD3
TABLE OF CONTENTS
1. SERVICING NOTES
............................................... 3
2. GENERAL ................................................................... 4
3. DISASSEMBLY
3-1. Disassembly Flow ........................................................... 5
3-2. Cabinet (Lower) Assy ...................................................... 5
3-3. Cabinet (Middle) Assy ..................................................... 6
3-4. Battery Block Sub Assy ................................................... 6
3-5. LCD Block Sub Assy, MAIN Board ............................... 7
3-6. HDD Unit ........................................................................\
8
3-7. Position of Ferrite Core ................................................... 8
4. TEST MODE .............................................................. 9
5. DIAGRAMS
5-1. Block Diagram - MAIN Section (1/2) - ......................... 18
5-2. Block Diagram - MAIN Section (2/2) - ......................... 19
5-3. Block Diagram - KEY/POWER SUPPLY Section - ...... 20
5-4. Printed Wiring Board - MAIN Section (1/2) - ............... 22
5-5. Printed Wiring Board - MAIN Section (2/2) - ............... 23
5-6. Schematic Diagram - MAIN Section (1/7) - .................. 24
5-7. Schematic Diagram - MAIN Section (2/7) - .................. 25
5-8. Schematic Diagram - MAIN Section (3/7) - .................. 26
5-9. Schematic Diagram - MAIN Section (4/7) - .................. 27
5-10. Schematic Diagram - MAIN Section (5/7) - .................. 28
5-11. Schematic Diagram - MAIN Section (6/7) - .................. 29
5-12. Schematic Diagram - MAIN Section (7/7) - .................. 30
5-13. Printed Wiring Board - HDD Section - .......................... 31
5-14. Schematic Diagram - HDD Section - ............................. 32
6. EXPLODED VIEW ................................................... 45
7. ELECTRICAL PARTS LIST ................................ 47
Notes on chip component replacement
- Never reuse a disconnected chip component.
- Notice that the minus side of a tantalum capacitor may be
damaged by heat.
Flexible Circuit Board Repairing - Keep the temperature of the soldering iron around 270 ΛC
during repairing.
- Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
- Be careful not to apply force on the conductor when soldering
or unsoldering.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE
WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE
PA RT NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR
IN SUPPLEMENTS PUBLISHED BY SONY.
Notes on the AC power adaptor
- Use only the AC power adaptor and the
USB adaptor supplied with the player. Do
not use any other AC power adaptor since
this may cause the player to malfunction.
- The player is not disconnected from the
AC power source (mains) as long as it is
connected to the wall outlet, even if the
player itself has been turned off.
- If you are not going to use the player for a
long time, be sure to disconnect the power
supply. To remove the AC power adaptor
from the wall outlet, grasp the adaptor plug
itself; never pull the cord.
Page 2
3
NW-HD3
SECTION 1
SERVICING NOTES
UNLEADED SOLDER
Boards requiring use of unleaded solder are printed with the lead-
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
- Unleaded solder melts at a temperature about 40 ΛC higher
than ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to about 350 ΛC.
Caution: The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so be careful!
- Strong viscosity
Unleaded solder is more viscous (sticky, less prone to flow)
than ordinary solder so use caution not to let solder bridges
occur such as on IC pins, etc.
- Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
- Replacement of CXR704060-201GA (IC1003),
S1R72003BOOA100 (IC2001), CXR710160-211GH
(IC3001), CXD1616GH (IC7001), EDL1216CASA-10L-E
(IC7002) and SC901584EPR2 (IC9002) used in this set
requires a special tool.
- When IC1101 and IC1102 (IC1102 is mounted only E, Hong
K ong, Taiwan, Korean, Chinese and Tourist models) are
damaged, exchange the new MAIN board for the MAIN board
which IC damaged.
System requirementsComputer IBM PC/AT or Compatible- CPU: Pentium II 400 MHz or higher (Pentium III 450 MHz or higher is
recommended.)
- Hard disk drive space: 200 MB or more (1.5 GB or more is recommended.) (The
amount of space will vary according to the Windows version and the number of
music files stored on the hard disk.)
- RAM: 64 MB or more (128 MB or more is recommended.)
Others -CD drive (capable of digital playback by WDM)
- Sound Board
- USB port (Hi-Speed USB is supported.)
Operating System Factory installed:
W indows XP Media Center Edition 2005/Windows XP Media Center Edition 2004/
W indows XP Media Center Edition/Windows XP Professional/
W indows XP Home Edition/Windows 2000 Professional/
W indows Millennium Edition/Windows 98 Second Edition
Display High Color (16 bit) or higher, 800 Γ 600 dots or better (1024 Γ 768 dots or better is
recommended.)
Others - Internet access: for Web registration, EMD services and CDDB
- W indows Media Player (version 7.0 or higher) installed for playing WMA files
Notes- SonicStage is not supported by the following environments:
- Operating systems other than those the indicated above
- Personally constructed PCs or operating systems
- An environment that is an upgrade of the original manufacturer-installed operating system
- Multi-boot environment
- Multi-monitor environment
- Macintosh
- We do not guarantee trouble-free operation on all computers that satisfy t\
he system requirement.
- The NTFS format of Windows XP/Windows 2000 Professional can be used only with the standard (factory)
settings.
- For Windows 2000 Professional users, install Service Pack 3 or later version before using the software.
- We do not guarantee trouble-free operation of the system suspend, sleep, o\
r hibernation function on the
computers.
Ve r. 1.3
