MV-700HR
2
Notes on chip component replacement- Never reuse a disconnected chip component.
- Notice that the minus side of a tantalum capacitor may be
damaged by heat.
Flexible Circuit Board Repairing - Keep the temperature of the soldering iron around 270 ËšC
during repairing.
- Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
- Be careful not to apply force on the conductor when soldering
or unsoldering.
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous radiation
e
xposure.
CAUTION
The use of optical instruments with this
product will increase eye hazard.
CAUTION :CLASS 1M VISIBLE/INVISIBLE LASER
RADIATION WHEN OPEN AND INTERLOCKS DEFEATED.
DO NOT VIEW DIRECTLY WITH OPTICAL INSTRUMENTS.
T his label is located on the drive unit's internal
chassis
This label is located on the bottom of the
chassis.
ADVARSEL
Eksplosjonsfare ved feilaktig skifte av batteri.
Benytt samme batteritype eller en tilsvarende type anbefalt av apparatfabrikanten.
Brukte batterier kasseres i henhold til fabrikantens instruksjoner.
V ARNING
Explosionsfara vid felaktigt batteribyte.
Använd samma batterityp eller en likvärdig typ som
rekommenderas av apparattillverkaren.
Kassera använt batteri enligt gällande föreskrifter.
VAROITUS
Pa risto voi räjähtää, jos se on virheellisesti asennettu.
V aihda paristo ainoastaan laitevalmistajan suosittelemaan tyyppiin.
Hävitä käytetty paristo valmistajan ohjeiden mukaisesti. ADVARSEL!
Lithiumbatteri-Eksplosionsfare ved fejlagtig håndtering. Udskiftning må kun ske med batteriaf samme fabrikat og type.
Levér det brugte batteri tilbage til leverandøren.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by
the manufacturer.
Discard used batteries according to the manufacturers instructions.
A TTENTION AU COMPOSANT AYANT RAPPORT
Ã- LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0 SUR
LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES
PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE
FONCTIONNEMENT. NE REMPLACER CES COM- POSANTS
Q UE PAR DES PIÈCES SONY DONT LES NUMÉROS SONT
DONNÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS
PUBLIÉS PAR SONY.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE
WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE
PA RT NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR
IN SUPPLEMENTS PUBLISHED BY SONY.
Design and specifications are subject to change
without notice.
On power sources- Use house current or a car battery (12 V DC).
- For use in your house, use the AC power
adaptor supplied with the player. Do not use
any other AC power adaptor since it may
cause the player to malfunction.
Polarity of
the plug - Abbreviation
AUS: Australian model
CH : Chinese model
CND: Canadian model
KR : Korean model
TW : Taiwan model
Ve r. 1.2
Page 2
MV-700HR
3
TABLE OF CONTENTS
1. SERVICING NOTES
................................................ 4
2. GENERAL
Location of Controls ........................................................ 6
3. DISASSEMBLY
3-1. Disassembly Flow ........................................................... 9
3-2. Cover (Hinge) .................................................................. 10
3-3. Front/Rear Case (Main) Section, Monitor Section .......... 10
3-4. Optical Pick-up Block (SDR-085T) ................................ 11
3-5. Memory Stick Connector, MAIN Board ......................... 11
3-6. Rear Case (LCD) Section ................................................ 12
3-7. MONITOR Board ............................................................ 12
3-8. Liquid Crystal Display Panel (LCD900) ......................... 13
4. TEST MODE .............................................................. 14
5. ELECTRICAL ADJUSTMENTS ......................... 15
6. DIAGRAMS
6-1. Block Diagram -“ DVD Section -“ .................................... 19
6-2. Block Diagram -“ AUDIO Section -“ ................................ 20
6-3. Block Diagram -“ VIDEO Section -“ ................................ 21
6-4. Block Diagram -“ POWER SUPPLY Section -“ ............... 22
6-5. Printed Wiring Board -“ MAIN Section (1/2) -“ ............... 24
6-6. Printed Wiring Board -“ MAIN Section (2/2) -“ ............... 25
6-7. Schematic Diagram -“ MAIN Section (1/4) -“ .................. 26
6-8. Schematic Diagram -“ MAIN Section (2/4) -“ .................. 27
6-9. Schematic Diagram -“ MAIN Section (3/4) -“ .................. 28
6-10. Schematic Diagram -“ MAIN Section (4/4) -“ .................. 29
6-11. Printed Wiring Board -“ MONITOR Section (1/2) -“ ....... 30
6-12. Printed Wiring Boards -“ MONITOR Section (2/2) -“ ...... 31
6-13. Schematic Diagram -“ MONITOR Section (1/4) -“ .......... 32
6-14. Schematic Diagram -“ MONITOR Section (2/4) -“ .......... 33
6-15. Schematic Diagram -“ MONITOR Section (3/4) -“ .......... 34
6-16. Schematic Diagram -“ MONITOR Section (4/4) -“ .......... 35
7. EXPLODED VIEWS
7-1. Overall Section ................................................................ 54
7-2. Rear Case (LCD) Section ................................................ 55
7-3. Front Case (LCD) Section ............................................... 56
7-4. Front Case (Main) Section .............................................. 57
7-5. Rear Case (Main) Section ................................................ 58
7-6. Connection Box Section (XA-121) ................................. 59
8. ELECTRICAL PARTS LIST ................................ 60
