Extracted text from sony mdp v 70 k service manual (Ocr-read)
Page 1
Ñ 2 Ñ
MODEL IDENTIFICATION
Ñ BACK PANEL Ñ
Parts No.
Parts No.Model
3-971-070-6
3-971-070-7
E model
Chinese model
Page 2
Ñ 3 Ñ
Notes on chip component replacement
¥ Never reuse a disconnected chip component.
¥ Notice that the minus side of a tantalum capacitor may be
damaged by heat.
CAUTIONUse of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous ra-
diation exposure.
SAFETY-RELATED COMPONENT WARNING !!
COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE
WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
