UK Model
AEP Model

SPECIFICATIONS

Radio section
Frequency range FM: 87t67107,5MHz
MW: 531-1,602 kHz

LW: 153-255 kHz

Antennas FM: FM wire antenna

MW/LW: Built»in ferrite bar antenna
Speaker Approx. 6.6 cm (25/9 inches) dia.
Power output 200 mW (at 10% harmonic distortion)
Output Earphone jack (mini jack)

Power requirements 220 V AC, 50 Hz (AEP model)

240 V AC, 50 Hz (UK model)
For the power backup function: 9V DC, one

6F22 battery

Battery life Approx. 80 hours, using Sony battery S-OOGP (U)
Dimensions Approx. 251 x 71 x 158 mm (w/h/d)

(10 x 27/: x 6]: inches)

incl. projecting parts and controls
Weight Approx. 750 g (12 02) not incl. battery

Design and specifications subject to change without notice.

SAFETY-RELATED COMPONENT WARNINGI!

COMPONENTS IDENTIFIED BV MARK A 0R DOTTED
LINE WITH MARK A ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL T0 SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.

FEATURES

0 Dual alarm FM/MW/LW 3-band radio combined with an electric digital
alarm clock and sleep timer.

. Choice of awakening to radio alarm, buzzer alarm. or dual alarm:
Alarm A (radio) and B (buzzer).

- 24~hour alarm preset system automatically turns alarm on at same
time each day.

- REPEAT ALARM/SLEEP OFF, operable with a feather-light touch,
offers functions; snooze alarm and sleep timer turn off.

. For private listening. this radio is equipped with an earphonejack.

- Fail-safe earphone jack: The alarm is heard through the
speaker when an earphone is connected.

DUAL ALARM FM/MW/LW
DIGITAL CLIICK RADII]

SONY.
