Page 1
- 2 -
HVR-MRC1
ENGLISH JAPANESE
ENGLISH JAPANESE
SPECIFICATIONS
System
File system
FAT32
CompactFlash 133x 2 GB or more
The capacity is the value when 1
GB equals 1 billion bytes.
The actual usable capacity may
be slightly less because
administrative files etc. are
included.
File format HDV recording MPEG-2TS
(.m2t)
DVCAM/DV recording AVI-Type1
(.AVI)
RAW DV (.DV)
Input signal HDV recording/playback Video: MPEG-2TS
1080/60i, 30p, 24p
1080/50i, 25p
Audio: 2 CH MPEG 1 Audio
Layer2 Stereo (16 bit 48 kHz)
(1/2 CH)
4 CH MPEG 2 Audio
Layer2 Stereo (16 bit 48 kHz)
(3/4 CH)
DVCAM/DV recording/playback Video: DV embedded
Audio: PCM digital
(12/16 bit, 32k, 48k)
Recordable time 2 GB Approx. 9 minutes
4 GB Approx. 18 minutes
8 GB Approx. 36 minutes
16 GB Approx. 72 minutes
General
Power requirement DC 7.2 V (battery pack) DC 8.4 V (AC adaptor)
Power consumption 2.2 W
Operating temperature 0 °C to 40 °C (32 °F to 104 °F)
Storage temperature -20 °C to +60 ° C (-4 °F to +140 ° F)
Operating humidity 20 % (20 °C) to 90 % (35 °C) (no condensation)
Dimensions HVR-MRC1 : Approx. 57 × 102 × 34 mm
(2 1/4 × 4 × 1 3/8 in.)
HVR-MRC1+HVRA-CR1: Approx. 77 × 106 × 51 mm (3 × 4 1/8 × 2 in.)
(including the projecting parts)
(w/h/d)
Mass HVR-MRC1 : Approx. 130 g (4.5 oz)
HVR-MRC1+HVRA-CR1: Approx. 210 g (7.4 oz) (excluding CompactFlash and
battery pack)
Input/output jack i.LINK
(IEEE1394 6-pin connector S400)
Optional accessories AC adaptor/charger AC-VQ1050B
Battery pack
NP-F570/F770/F970
Design and specifications are subject to change without
notice.
Downloaded From http://www.free-service-manuals.com
Page 2
- 3 -
HVR-MRC1
ENGLISH JAPANESE
ENGLISH JAPANESE
t7
³µÂÜ
Ñ ç³µÂÜ FAT32
¯ïÍ«ÄÑ忳á 133x 2 GB Ž Í
0xz
1 GB - 10 /Ì Äp--`
h -ùw
:-pb{
-hg;Ñ çsr--hŠz
îM-;pV0x ïn -b -
ùUK-b{
Ñ çÑ¥Ú¿Ä
HDV GåÌ MPEG-2TS ¢ .<
