Page 1
Ð 2 Ð
MODEL IDENTIFICATION
Ð BACK PANEL Ð
MODEL PARTS NO.
GR8 : EA3 model 4-986-845-1¹
GR8 : MY model 4-986-845-2¹
GR8 : E3, IA models 4-988-021-0¹
GR8 : E2 model 4-988-021-1¹
GR8 : SP model 4-988-021-2¹
GR8 : TW, JE models 4-988-021-3¹
GR8 : HK model 4-988-021-4¹
GR8 : AUS model 4-988-021-5¹
GR8 : MX model 4-988-021-6¹
GR8 : EA4, TH, SAF models 4-988-021-7¹
RX90 : AEP model (Made in Malaysia) 4-986-845-0¹
RX90 : AEP (Made in Indonesia), AED,
G, UK models4-986-982-0¹
RX90 : EE, CIS model 4-986-982-1¹
¥ Abbreviation
AED : Northern European
AUS : Australian
E2 : 120 V AC Area in E model
E3 : 240 V AC Area in E model
EA3 : Saudi Arabia
EA4 : Israeli
EE : East European
G : German
HK : Hong Kong
IA : Indonesia
JE : Tourist
MX : Mexican
MY : Malaysia
SAF : South African
SP : Singapore
TH : Thailand
TW : Taiwan
PARTS No.
Tuner section
FM stereo, FM/AM superheterodyne tuner
FM tuner section
Tuning range
EE and CIS models: 65.0 Ð 74.0 MHz
87.5 Ð 108.0 MHz
Other models: 87.5 Ð 108.0 MHz
Aerial FM lead aerial
Aerial terminals 75 ohm unbalanced
Intermediate frequency 10.7 MHz
UKV tuner section (EE and CIS models)
Tuning range 65.0 Ð 74.0 MHz
Polar stereo
AM tuner section
Tuning range
RX90: MW: 531 Ð 1,602 kHz
(with interval set at 9kHz)
LW: 153 Ð 279 kHz
(with interval set at 3kHz)
MX, AUS, EA4 and TH models:
531 Ð 1,602 kHz
(with the AM tuning interval st at 9 kHz)
530 Ð 1,710 kHz
(with the AM tuning interval set at 10 kHz)
Other models MW: 531 Ð 1,602 kHz
(With the MW tuning interval set at 9 kHz)
530 Ð 1,710 kHz
(With the MW tuning interval set 10 kHz)
SW: 5.95 Ð 17.9 MHz
(with the SW tuning interval set at 5 kHz)
Aerial AM loop aerial
Aerial terminals External aerial terminal
Intermediate frequency 450 kHz
General
Power requirements
RX90: 220 Ð 230 V AC, 50/60 Hz
MX model: 120 V AC, 50/60 Hz
MY and AUS models: 220 Ð 240 V AC, 50/60 Hz
TH model: 220 V AC, 50 Hz
Other models: 110 Ð 120 V or 220 Ð 240 V
AC, 50/60 Hz Adjustable with voltage selector
Power consumption
RX90: 230 watts
GR8: 220 watts
Mass: Approx. 9.5 kg
Supplied accessories: AM loop aerial (1)
Remote RM-SD80 (1)
Sony SUM-3 (NS)
Batteries (2)
FM lead aerial (1)
Speaker cords (4)
Design and specifications are subject to change without notice.
Page 2
Ð 3 Ð
CAUTION
Use of controls or adjustments or performance of
procedures other than those specified herein may
result in hazardous radiation exposure.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK ! OR DOTTED
LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.
This appliance is classified as a CLASS 1 LASER product.
The CLASS 1 LASER PRODUCT MARKING is located on
the rear exterior.
Laser component in this product is capable of emitting radiation
exceeding the limit for Class 1.
The following caution label is located inside the unit.
