HCD-CP300
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH
MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.ATTENTION AU COMPOSANT AYANT RAPPORT
Ă- LA SĂCURITĂ!
LES COMPOSANTS IDENTIFĂS PAR UNE MARQUE 0 SUR LES
DIAGRAMMES SCHĂMATIQUES ET LA LISTE DES PIĂCES SONT
CRITIQUES POUR LA SĂCURITĂ DE FONCTIONNEMENT. NE
REMPLACER CES COMPOSANTS QUE PAR DES PIĂSES SONY
DONT LES NUMĂROS SONT DONNĂS DANS CE MANUEL OU
DANS LES SUPPĂMENTS PUBLIĂS PAR SONY.
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
This appliance is classified as a CLASS 1 LASER product.
The CLASS 1 LASER PRODUCT MARKING is located on
the rear exterior.
Laser component in this product is capable of emitting radiation
exceeding the limit for Class 1.
The following caution label is located inside the unit.
CAUTION : INVISIBLE LASER RADIATION WHEN OPEN AND
INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM.
ADVARSEL : USYNLIG LASERSTRĂ
LING VED Ă
BNING NĂ
R
SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION. UNDGĂ
UDSAETTELSE
FOR STRĂ
LING.
VORSICHT : UNSICHTBARE LASERSTRAHLUNG, WENN
ABDECKUNG GEĂFFNET UND SICHEREITSVERRIEGELUNG
ĂBERBRĂCKT. NICHT DEM STRAHL AUSSETZEN.
VA R O ! :AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET ALT-
TIINA NĂKYMĂTTĂMĂLLE LASERSĂTEILYLLE. ĂLĂ KATSO SĂTEESEEN.
VARNING : OSYNLING LASERSTRĂ
LING NĂR DENNA DEL ĂR ĂPPNAD
OCH SPĂRREN ĂR URKOPPLAD. BETRAKTA EJ STRĂ
LEN.
ADVERSEL : USYNLIG LASERSTRĂ
LING NĂ
R DEKSEL Ă
PNES OG
SIKKERHEDSLĂ
S BRYTES. UNNGĂ
EKSPONERING FOR STRĂ
LEN.
VIGYAZAT !:A BURKOLAT NYITĂSAKOR LĂTHATATLAN LĂZERSU-
GĂRVESZĂLY ! KERĂLJE A BESUGĂRZĂST !
Notes on chip component replacement
-Never reuse a disconnected chip component.
-Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.
Flexible Circuit Board Repairing
-Keep the temperature of the soldering iron around 270 ËC dur-
ing repairing.
-Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
-Be careful not to apply force on the conductor when soldering
or unsoldering.SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety check before releasing the set to the customer:
Check the antenna terminals, metal trim, metallized knobs, screws,
and all other exposed metal parts for AC leakage.
Check leakage as described below.
LEAKAGE TEST
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microamperes.).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or
RCA WT-540A. Follow the manufacturers instructions to use
these instruments.
2. A battery-operated AC milliammeter. The Data Precision
245 digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a
VOM or battery-operated AC voltmeter. The limit indication
is 0.75 V, so analog meters must have an accurate low-voltage
scale. The Simpson 250 and Sanwa SH-63Trd are examples of
a passive VOM that is suitable. Nearly all battery operated digital
multimeters that have a 2 V AC range are suitable. (See Fig. A)
Fig. A. Using an AC voltmeter to check AC leakage.
1.5 k -Š 0.15 ”F AC
voltmeter
(0.75 V) To Exposed Metal
Parts on Set
Earth Ground
