Page 1
2
Welcome!
Thank you for purchasing this Sony CD/
DVD Player. Before operating the unit,
please read this manual thoroughly and
retain it for future reference.
WARNING
To prevent fire or shock
hazard, do not expose the
unit to rain or moisture.
To avoid electrical shock,
do not open the cabinet.
Refer servicing to qualified
personnel only.
CAUTION
The use of optical instruments with this
product will increase eye hazard. As the
laser beam used in this CD/DVD player is
harmful to eyes, do not attempt to
disassemble the cabinet.
Refer servicing to qualified personnel only.
This label is located on the Laser protective
housing inside the enclosure.
This symbol is intended to
alert the user to the presence
of uninsulated Òdangerous
voltageÓ within the productÕs
enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
This symbol is intended to
alert the user to the presence
of important operating and
maintenance (servicing)
instructions in the literature
accompanying the appliance.
CAUTION
TO PREVENT ELECTRIC SHOCK
MATCH WIDE BLADE OF PLUG TO
WIDE SLOT, FULLY INSERT.
For customers in the U.S.A
OwnerÕs Record
The model and serial numbers are
located at the rear of the unit. Record the
serial number in the space provided below.
Refer to them whenever you call upon
your Sony dealer regarding this product.
Model No. DVP-S570D
Serial No.______________
CAUTION
You are cautioned that any change or
modifications not expressly approved in
this manual could void your authority to
operate this equipment.
NOTE:
This equipment has been tested and found
to comply with the limits for a Class B
digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses, and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur
in a particular installation. If this
equipment does cause harmful
interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user
is encouraged to try to correct the
interference by one or more of the
following measures:
Ð Reorient or relocate the receiving
antenna.
Ð Increase the separation between the
equipment and receiver.
Ð Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
Ð Consult the dealer or an experienced
radio/TV technician for help.
Page 2
3
T ABLE OF CONTENTS
About This Manual 4
This Player Can Play the Following Discs 4
Precautions 6
Notes About the Discs 6
Getting Started 7
Unpacking 7
TV Hookups 8
Receiver (Amplifier) Hookups 10
5.1 Channel Surround Hookups 12
Selecting the Language for the On-Screen
Display 14
Operation Sound Effects (Sound Feedback) 15
Playing Discs 16
Playing Discs 16
Playing at Various Speeds/Frame by Frame 18
Resuming Playback from the Point Where You
Stopped the Disc (Resume Play) 20
Using the DVDÕs Menu 21
Playing VIDEO CDs with PBC Functions
(PBC Playback) 22
Using the Front Panel Display 23
Using Various Functions with the
Control Menu 25
Using the Control Menu Display 25
Control Menu Item List 27
Searching for a Title/Chapter/Track/
Index/Scene 28
Checking the Playing Time and Remaining
Time 29
Selecting a Starting Point Using the Time Code 30
Labeling the Disc 31
Changing the Sound 32
Displaying the Subtitles 34
Changing the Angles 35
Digital Cinema Sound Settings 36
Checking the Play Information 39
Locking Discs (Custom Parental Control) 40
Creating Your Own Program (Program Play) 41
Playing in Random Order (Shuffle Play) 43
Playing Repeatedly (Repeat Play) 44
Repeating a Specific Portion (AÐB Repeat) 45Adjusting the Playback Picture
(Video Equalizer) 46
Enhancing the Playback Picture
(Digital Video Enhancer) 48
Using the Quick Reference Screen (VIEWER) 48
Settings and Adjustments 51
Using the Setup Display 51
Setup Display Item List 53
Setting the Display Language or Sound Track
(LANGUAGE SETUP) 54
Settings for the Display (SCREEN SETUP) 55
Custom Settings (CUSTOM SETUP) 56
Settings for the Sound (AUDIO SETUP) 60
Settings for the Speakers (SPEAKER SETUP) 62
Controlling Your TV or AV Receiver (Amplifier)
with the Supplied Remote 65
Additional Information 67
Troubleshooting 67
Self-diagnosis function 70
Specifications 71
Glossary 72
Language Code List 74
Index to Parts and Controls 75
Index 78
