Radio ID
Menu icon
Menu item
Channel Category
Channel NumberChannel Name
Memory number
2 seconds * The POWER and preset button No. 3 have a tactile dot.
Remote commander
Preset buttons
Parts and Identifications
Main unit
Display window
DSPL/BACK
MEMO JOG roller (MENU/ENTER)
Preset buttons (1-5)*
Remote sensorPOWER*Cradle release button Cradle
release
button
* The X and POWER button have a tactile dot.
Using the JOG Roller (MENU/
ENTER)
Turn up or down to select channels,
select the menu items and settings, or
scroll the stored text information in
the menu operation.
Press to display the menu display, or
execute the items or settings in the
menu operation.
Displaying the Radio ID
The receiver has its own ID, and an ID number is required when
registering in XM.
1 Press POWER to turn on the main unit. 2 Turn JOG roller (or press X - x on the remote) to select
XM CH0 RADIO ID. The radio ID appears.
CHO RADIO ID
XXXXXXXXXM
Note
The Radio ID can be displayed only in Channel Scroll mode. See Playing
the Receiver.
Preset number
Artist Name/FeatureSong/Program Title
Additional InformationCurrent time and date
Adjusting the Time Difference
This unit displays the current time by correcting the time difference
between the local time and UTC (coordinated universal time) data being
transmitted. Set the hour of your local time in the menu display. The
factory-set is the eastern standard time.
If the current UTC data is not received, - - : - - appears in the display.
1 Press POWER to turn on the main unit. 2 Press JOG roller (or MENU on the remote) to show the
menu display.
The first menu item appears.
SCROLL MODE MENU
3 Turn JOG roller (or press X - x on the remote) to select
TIME ADJUST and press JOG roller (or ENTER on the
remote).
The hour flashes.
TIME ADJUST
11:12AM MENU
12:00 AM = midnight
12:00 PM = noon
4 Turn JOG roller (or press X - x on the remote) to adjust the
hour and press JOG roller (or ENTER on the remote).
The display returns to the tuned channel display.
Note
This unit does not have the Daylight Saving Time (summer time)
function.
To check the current time while listening to a
broadcast
Press DSPL/BACK (or DSPL on the remote) until the INFO and TIME
display appears. See Checking the Tuned Channel Information.
To cancel a selectionPress DSPL/BACK (or BACK on the remote) to return to the previous
display during menu operation.
Press MENU on the remote commander to exit the menu display. The
display returns to the tuned channel display.
Playing the Receiver
Notes
- Turn down the volume of the component connected to the unit before
playing the unit.
- Adjust the volume of the component connected to the unit.
- If sound distortion occurs when playing the unit with the cassette
adaptor, adjust the Line Out Level. See Using Other Functions.
Manual Tuning
1 Make settings on your car audio or amplifier, etc. so that you
can listen to the sound from this unit.
2 Press POWER to turn on the main unit.The channel that you last tuned in to is displayed.
CH13
TOP 20XMCHAN
3 Turn JOG roller (or press X - x on the remote) to select
desired channel.
- Holding down X - x makes the channel readout to rapidly increase or
decrease respectively.
- This unit has two scroll modes: Channel Scroll and Category Scroll. See
Using the Category Scrolls.
Channel Scroll: searches for a channel by scrolling every single channel
among authorized channels.
Category Scroll: searches for a channel using the Channel Category you
selected in the menu display.
To turn off the receiverPress POWER.
Using the Category Scrolls
In Category Scroll mode, you can search for a channel among authorized
channels that have the corresponding Channel Category you selected in
the menu display.
1 Press JOG roller (or MENU on the remote) to show the
menu display.
SCROLL MODE appears in the display. 2 Press JOG roller (or MENU on the remote).The current scroll mode appears in the display.
SCROLL MODE
CHANNEL SCROLLMENU
3 Turn JOG roller (or press X - x on the remote) to select
CATEGORY SCROLL and press JOG roller (or ENTER on
the remote).
The selected Channel Category appears in the display.
CATEGORY SCROLL
NEWSMENU
4 Turn JOG roller (or press X - x on the remote) to select the
desired Channel Category and press JOG roller (or ENTER
on the remote).
The unit searches for a channel that has the selected Channel Category
from the Channel Number next to the current channel.
The CATEGORY indicator appears in the upper left corner of the
display.
To cancel a selectionPress DSPL/BACK (or BACK on the remote) to return to the previous
display during menu operation.
Press MENU on the remote commander to exit the menu display. The
display returns to the tuned channel display.
Tips
- When you tune in to a channel in Category Scroll mode, the Channel
Category appears for about 2 seconds in the display.
CH50
NewsXMCAT
