Page 1
Playing tracks in your
favorite order
(PGM play)
You can program the CD player to play up to 64 tracks in
your favorite order.
1 During playback, press PLAY MODE repeatedly until
PGM appears.
2 Push the 3-way control key toward . or > to
select a track.
3 Press REPEAT/ENTER to enter the selected track.
00 appears and the playing order increases by one.
4 Repeat steps 2 and 3 to select the tracks in your
favorite order.
5 Hold down REPEAT/ENTER to start PGM play.
To check the programDuring programming:
Press REPEAT/ENTER repeatedly before step 5.
During the PGM play:
Press PLAY MODE repeatedly until PGM flashes, then
press REPEAT/ENTER.
Each time you press REPEAT/ENTER, the track number
appears.
Notes- When you finish entering the 64th track in step 3, the first
selected track appears in the display.
- If you select more than 64 tracks, the first selected
tracks are erased.
Wearing the supplied
headphones
The following procedures are for wearing on the left ear.
1 Hook the L part over your left ear and the R part
over your right ear as illustrated.
2 Hook the headphones around your ears, as you would
with glasses.
3 Adjust the earpieces to comfortably fit your ears.
Notes on handling the supplied
headphones
- Avoid rough handling or mechanical shock. Be
particularly careful of the headphone part.
- Do not put force or weight on the unit for a long time as
that may damage or deform the unit.
- Do not leave the unit in a location subject to moisture,
dust, smoke, steam or direct sunlight.
- Clean the plug with a soft dry cloth. A dirty plug may
cause the sound quality to deteriorate.
- Clean the headphone part with a soft dry cloth.
- After you use the headphones, keep them with the cord
slider positioned high to avoid entangling the cord.
Using the hand strap
During active uses, use the supplied hand strap.
1 Pass the strap through the hooks.
2 Put your hand between the player and the strap, then
adjust the length of the strap and fix it using the
Velcro tapes.
Precautions
On safety- Should any solid objects or liquid fall into the CD
player, unplug it and have it checked by qualified
personnel before operating it any further.
- Do not put any foreign objects in the DC IN 4.5 V
(external power input) jack.
On power sources- When you are not using the CD player for a long time,
disconnect all power sources from the CD player.
On AC power adaptor- If your CD player is not supplied with the AC power
adaptor, use the AC-E45HG AC power adaptor. Do not
use any other AC power adaptor. It may cause a
malfunction.
Polarity of the plug
- Do not touch the AC power adaptor with wet hands.
- Connect the AC power adaptor to an easily accessible
AC outlet. Should you notice an abnormality in the AC
power adaptor, disconnect it from the AC outlet
immediately.
On rechargeable batteries and dry
batteries
- Do not charge the dry batteries.
- Do not throw the batteries into fire.
- Do not carry the batteries with coins or other metallic
objects. It can generate heat if the positive and negative
terminals of the battery are accidentally contacted by a
metallic object.
- Do not mix rechargeable batteries with dry batteries.
- Do not mix new batteries with old ones.
- Do not use different types of batteries together.
- When the batteries are not to be used for a long time,
remove them.
- If battery leakage occurs, wipe off any deposit in the
battery compartment, and install new batteries. In case
the deposit adheres to you, wash it off thoroughly.
On the CD player- Keep the lens on the CD player clean and do not touch
it. If you do so, the lens may be damaged and the CD
player will not operate properly.
- Do not put any heavy object on top of the CD player.
The CD player and the CD may be damaged.
- Do not leave the CD player in a location near heat
sources, or in a place subject to direct sunlight,
excessive dust or sand, moisture, rain, mechanical
shock, unleveled surface, or in a car with its windows
closed.
- If the CD player causes interference to the radio or
television reception, turn off the CD player or move it
away from the radio or television.
- Discs with non-standard shapes (e.g., heart, square, star)
cannot be played on this CD player. Attempting to do so
may damage the CD player. Do not use such discs.
On headphones/earphones
Road safety
Do not use headphones/earphones while driving, cycling,
or operating any motorized vehicle. It may create a traffic
hazard and is illegal in some areas. It can also be
potentially dangerous to play your headsets at high
volume while walking, especially at pedestrian crossings.
You should exercise extreme caution or discontinue use in
potentially hazardous situations.
Preventing hearing damageAvoid using headphones/earphones at high volume.
Hearing experts advise against continuous, loud and
extended play. If you experience a ringing in your ears,
reduce volume or discontinue use.
Consideration for othersKeep the volume at a moderate level. This will allow you
to hear outside sounds and to be considerate to the people
around you.
On the water resistance- Before unfastening the buckle to open the lid, be sure to
wipe off water, dust or sand on the exterior of the unit.
Open and close the lid where water or sand cannot fall
in the unit, and make sure that your hands are dry. If
water or sand falls in the unit, trouble may occur.
- When closing the lid, check that there is no dust or sand
on the rubber packing around the lid. Then close the lid
firmly with the buckle.
- The supplied headphones are not meant to be immersed
in water or come in continuous contact with water. If
they are accidentally dropped into water or get wet, dry
them with a soft cloth. Never use an electric hair dryer.
- The AC power adaptor is not water resistant. To prevent
shock hazard, avoid using the player near water during
AC operation.
- Cover the DC IN 4.5 V jack and i jack with the
attached rubber caps when nothing is connected to these
jacks. If the inside of the jacks are contaminated with
water or sand, rust may develop and cause trouble.
This warranty is valid only in the United States.
-4.5
Notes- Since the unit is airtight, you may not be able to open the lid
when there is a sudden change in air pressure inside the unit.
This happens when the unit is transported on a plane or
moved from a warm place to a cold place. In this case, open
the rubber cap on the DC IN 4.5 V jack.
- To prevent water from leaking in, the buckle is designed to
be slightly stiff. Be careful not to catch a fingernail on the
buckle when unfastening the lid.
Do not hold the player with the buckle by
itself. Doing so may damage the unit.
Maintenance
To clean the casingUse a soft cloth slightly moistened in water or a mild
detergent solution. Do not use alcohol, benzine or thinner.
To clean the headphones plugKeep the plug of your headphones clean to obtain
optimum sound. Wipe it with a dry, soft cloth.
To remove any dust or sand from the
rubber packing
Any sand or dust on the rubber packing will prevent the
lid from shutting tightly, and water may leak in. Brush off
the dust once in a while.
We recommend the replacement of the rubber packing
every year which is available optionally at an authorized
Sony service facility.
Troubleshooting
Should any problem persist after you have made these
checks, consult your nearest Sony dealer.
Hold appears in the display when you
press a button, and the CD does not
play.
cThe buttons are locked. Slide HOLD back.
The volume does not increase even if
the VOL control is adjusted to the
maximum level.
cPress and hold SOUND until AVLS disappears from
the display.
The battery compartment lid is
detached by an accidental drop,
excessive force, etc.
cAttach it as illustrated below.
Specifications
SystemCompact disc digital audio system
Laser diode propertiesMaterial: GaAlAs
Wavelength: λ = 780 nm
Emission duration: Continuous
Laser output: Less than 44.6 µW (This output is the value
measured at a distance of 200 mm from the objective lens
surface on the optical pick-up block with 7 mm aperture.)
D-A conversion1-bit quartz time-axis control
Frequency response40 - 20 000 Hz 0
dB (measured by JEITA CP-307)
Output (at 4.5 V input level)Headphones (stereo minijack)
Approx. 5 mW + Approx. 5 mW at 16 -
Power requirements- Sony NH-WM2AA rechargeable batteries:
1.2 V DC × 2
- LR6 (size AA) batteries: 1.5 V DC × 2
- AC power adaptor (DC IN 4.5 V jack):
220 V, 50 Hz (Model for China)
120 V, 60 Hz (Model for Mexico)
Dimensions (w/h/d) (including
projecting parts and controls)
Approx. 133.9 × 38.1 × 147.5 mm
(5 3-8 × 1 1-2 × 5 7-8 in.)
Mass (excluding accessories)Approx. 360 g (12.7 oz)
Operating temperature5°C - 35°C (41°F - 95°F)
Design and specifications are subject to change without
notice.
Supplied Accessories
Headphones (1)
Hand strap (1)
