D-NE240/NE241/NE241CK
TABLE OF CONTENTS
1. SERVICING NOTES
............................................... 3
2. GENERAL ................................................................... 4
3. DISASSEMBLY
3-1. Disassembly Flow ........................................................... 5
3-2. Cabinet (Lower) Assy ...................................................... 5
3-3. MAIN Board, CD Mechanism (CDM-3525A) ............... 6
3-4. Cabinet (Inner) Assy, SWITCH Board ............................ 6
4. TEST MODE .............................................................. 7
5. ELECTRICAL CHECK ........................................... 7
6. DIAGRAMS
6-1. Printed Wiring Board - SWITCH Board - ..................... 9
6-2. Printed Wiring Board - MAIN Board (Component Side) - ............................... 10
6-3. Printed Wiring Board - MAIN Board (Conductor Side) - ................................. 11
6-4. Schematic Diagram - MAIN Section (1/2) - .................. 12
6-5. Schematic Diagram - MAIN Section (2/2) - .................. 13
7. EXPLODED VIEWS
7-1. Upper Lid and Cabinet (Inner) Section ........................... 17
7-2. Cabinet Lower Section .................................................... 18
8. ELECTRICAL PARTS LIST ................................ 19 Notes on chip component replacement
- Never reuse a disconnected chip component.
- Notice that the minus side of a tantalum capacitor may be
damaged by heat.
Flexible Circuit Board Repairing - Keep the temperature of the soldering iron around 270 ΛC
during repairing.
- Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
- Be careful not to apply force on the conductor when soldering
or unsoldering.
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous radiation
e xposure.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE
WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE
PA RT NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR
IN SUPPLEMENTS PUBLISHED BY SONY.
On the AC power adaptor - Use only the AC power adaptor supplied. If your player is not supplied with an AC
power adaptor, use an AC-E45HG AC power
adaptor*. Do not use any other AC power
adaptor. It may cause a malfunction.
* Not available in Australia and some other regions. Ask your dealer for detailed
information. Polarity of the
plug
- Do not touch the AC power adaptor with wet hands.
- Connect the AC power adaptor to an easily accessible AC outlet. Should you notice an abnormality in the AC power adaptor,
disconnect it from the AC outlet immediately.
