-“ 2 -“ - The equipment can be removed using the following procedure. SECTION 1 DISASSEMBLY Note : Follow the disassembly procedure in the numerical order given. 1-1. CABINET (REAR) SUB ASSY, CABINET (FRONT), MAIN BOARD Set Cabinet (Rear) Sub Assy, Cabinet (Front), Main Board Motor Assy, Turn Table (Spindle) (M901) Motor Assy, Sled (M902), Optical Pick-up (DAX-23E) Switch Unit MD Assy 1-2. MD ASSY 4 screws (B2) 6 9 2 screw (B2) 1 lid. battery 3 knob (open) 8 FLEXIBLE board (CN801 ) 0 MAIN board 7 cabinet (front) lid, upper 5 claws qa cabinet (rear) sub assy 5 claws 5 claws 5 claws 4 1 CN502 (red) 2 CN503 (white)5 MD assy 3 optical pick-up flexible board MAIN boar d

Page 2

-“ 3 -“-“ 4 -“ 1-3. MOTOR ASSY, TURN TABLE (SPINDLE) (M901)1-4. MOTOR ASSY, SLED (M902), OPTICAL PICK-UP (DAX-23E) 23 motor assy, turn tabl e (spindle) (M901) chassis 1 B 1.7x5 5 qa 9 31 B 1.7x5 7 P 1.4x3.5 qs screw (feed) assy chassis 0 optical pick-up (DAX-23E) 8 bracket (shaft) 4 gear (B) 2 cover, gear 6 motor assy ,sled (M902) 1-5. SWITCH UNIT 2 4 3 1 knob (open) 7 cover, lidlid, upper cabinet (front) 6 claws 6 claws8 switch unit 5 screws spring (full open) qs window, LCD qa button (FF&FR) 0 button (mode)9 button (play) SECTION 2 EXPLODED VIEW 2-1. CABINET SECTION NOTE:- The mechanical parts with no reference number in the exploded views are not supplied. - Accessories and packing materials are given in the last of this parts list.- Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. - Abbreviation AR : Argentina model CND : Canadian model CDM-3223EBA 1 3 2 4 5 6 7 8 9 10 10 111213 14 151617 1819 520 21 22 2324 25 26 27 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1 A-3323-401-A MAIN BOARD, COMPLETE 2 4-223-584-01 TERMINAL (-“), BATTERY 3 4-223-585-01 TERMINAL (+), BATTERY 4 A-3328-742-A CABINET (REAR) SUB ASSY 5 3-719-408-01 SCREW (B2), TAPPING, P3 6 4-223-606-01 LID, BATTERY 7 4-966-278-01 FOOT, RUBBER 8 4-993-131-01 KNOB (HOLD) 9 4-223-586-01 TERMINAL, BATTERY LINK 10 3-375-114-31 SCREW 11 3-044-063-01 COVER, LID 12 1-418-849-11 SWITCH UNIT 13 3-044-068-01 BUTTON (PLAY) 14 3-044-067-01 BUTTON (MODE)15 3-044-066-01 BUTTON (FF&FR) 16 3-044-065-01 COVER, DECORATION 17 3-047-205-01 SHEET (LCD WINDOW), ADHESIVE 18 3-044-064-01 WINDOW, LCD 19 X-3379-487-1 LID (UPPER) SUB ASSY (US,CND,E,AR) 19 X-3379-488-1 LID (UPPER) SUB ASSY (UK) 20 4-223-587-01 SPRING (FULL OPEN) 21 4-223-603-01 CABINET (FRONT) 22 4-223-607-01 BUTTON (VOLUME) 23 4-222-793-11 KNOB (OPEN) 24 4-222-792-01 LEVER, DETECTOR 25 4-222-794-01 CLAW, LOCK 26 4-223-583-01 SPRING (OPEN) 27 4-223-609-01 KNOB (JOGGABLE)The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une piéce portant le numéro spécifié.
