Specifications ............................................................................ 1
1. SERVICING NOTES ................................................... 3
2. GENERAL ...................................................................... 4
3. DISASSEMBLY
3-1. Lid Assy, Upper .......................................................... 5
3-2. Cabinet (Front) Assy, Cabinet (Rear) Assy,
MD Assy ..................................................................... 5
3-3. Main Board ................................................................. 6
4. SERVICE MODE.................................................... 7
5. ADJUSTMENTS
.......................................................... 8
6. DIAGRAMS
6-1. Explanation of IC Terminals ...................................... 11
6-2. Block Diagram .......................................................... 13
6-3. Printed Wiring Boards .............................................. 16
6-4. Schematic Diagram ................................................... 19
7. EXPLODED VIEWS
7-1. Cabinet Section ......................................................... 28
7-2. Optical Pick-up Section ............................................ 30
8. ELECTRICAL PARTS LIST ................................... 31
ATTENTION AU COMPOSANT AYANT RAPPORT
Ë LA SƒCURITƒ!
LES COMPOSANTS IDENTIFIƒS PAR UNE MARQUE ! SUR LES
DIAGRAMMES SCHƒMATIQUES ET LA LISTE DES PIéCES
SONT CRITIQUES POUR LA SƒCURITƒ DE FONCTIONNEMENT.
NE REMPLACER CES COMPOSANTS QUE PAR DES PIéCES
SONY DONT LES NUMƒROS SONT DONNƒS DANS CE MANUEL
OU DANS LES SUPPLƒMENTS PUBLIƒS PAR SONY.SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH
MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS
LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE
PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN
SUPPLEMENTS PUBLISHED BY SONY.Flexible Circuit Board Repairing
¥ Keep the temperature of the soldering iron around 270°C during
repairing.
¥ Do not touch the soldering iron on the same conductor of the circuit
board (within 3 times).
¥ Be careful not to apply force on the conductor when soldering or
unsoldering.
Notes on chip component replacement
¥ Never reuse a disconnected chip component.
¥ Notice that the minus side of a tantalum capacitor may be damaged
by heat.
TABLE OF CONTENTS
This Compact Disc player is
classified as a CLASS 1 LASER
product.
The CLASS 1 LASER
PRODUCT label is located on the
bottom exterior. CAUTION
Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure. DANGER
Invisible laser radiation when open and interlock failed or defeated.
Avoid direct exposure to beam.
D-E441SR
AC power adaptor (1)
Earphones (1)
Active speaker system (1)
D-E443
AC power adaptor (1)
Earphones (1)
Rechargeable battery (1)
AC plug adaptor (1)*
* Supplied with E33, E13 and EA models
D-E445
AC power adaptor (1)
Headphones with remote control (1) *
1
Earphones with remote control (1) * 2
Rechargeable battery (1)
AC plug adaptor (1)* 3
*1Supplied with US model
*2Not supplied with US model
*3Supplied with E13 model
D-E446CK
AC power adaptor (1)
Headphones (1) *
1
Earphones (1) * 2
Car battery cord (1)
Car connecting pack (1)
Velcro tape (2)
Spare fuse (1)
Spiral tube (1)
AC plug adaptor (1)*
3
*1Supplied with US model
*2Not supplied with US model
*3Supplied with E33, E13 and EA models
D-E449CK
AC power adaptor (1)
Rechargeable battery (1)
Headphones with remote control (1)
Car battery cord (1)
Car connecting pack (1)
Velcro tape (2)
Spare fuse (1)
Spiral tube (1)
Design and specifications are subject to change without notice.
Page 2
Ð 3 Ð
The laser diode in the optical pick-up block may suffer electrostatic
breakdown because of the potential difference generated by the charged
electrostatic load, etc. on clothing and the human body. During repair,
pay attention to electrostatic breakdown and also use the procedure in
the printed matter which is included in the repair parts.
The flexible board is easily damaged and should be handled with care.
NOTES ON LASER DIODE EMISSION CHECK
The laser beam on this model is concentrated so as to be focused on the
disc reflective surface by the objective lens in the optical pick-up block.
Therefore, when checking the laser diode emission, observe from more
than 30cm away from the objective lens.
Before Replacing the Optical pick-up Block
Please be sure to check thoroughly the parameters as per the ÒOptical
pick-up Block Checking ProcedureÓ (Part No. : 9-960-027-11) issued
separately before replacing the optical Pick-up block.
Note and specifications required to check are given below.
¥ FOK output : IC501 !ª pin
When checking FOK, remove the lead wire to disc motor.
¥ S curve P-to-P value : 1.2±0.3Vp-p IC501 #Á pin. (Connect pin !ª of
IC501 (TP880) and 3 of IC501 (GND) with a jumper wire).
When checking S curve P-to-P value, remove the lead wire to disc
motor.
¥ Adjusted part for focus gain adjustment : RV503
¥ RF signal P-to-P value : 0.8 Ð 1.2Vp-p
¥ Traverse signal P-to-P value : 1.0 Ð 2.4Vp-p
¥ The repairing grating holder is impossible.
¥ Adjusted part for tracking gain adjustment : RV502
SECTION 1
SERVICING NOTES
Precautions for Checking Emission of Laser Diode
Laser light of the equipment is focused by the object lens in the optical
pick-up so that the light focuses on the reflection surface of the disc.
Therefore, be sure to keep your eyes more then 30cm apart from the
object lens when you check the emission of laser diode.
Laser Diode Checking Methods
During normal operation of the equipment, emission of the laser diode
is prohibited unless the upper panel is closed while turning ON the S801
(push switch type).
The following two checking methods for the laser diode are operable.
Method-1 (In the service mode or normal operation) :
Emission of the laser diode is visually checked.
1. Open the upper lid.
2. Push the S801 as shown in Fig. 1 .
3. Check the object lens for confirming normal emission of the laser
diode. If not emitting, there is a trouble in the automatic power
control circuit or the optical pick-up. During normal operation, the
laser diode is turned ON about 2.5 seconds for focus searching.
Fig. 2 Digital Voltmeter Connecting Location
NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR
BASE UNIT
Method-2 (In the service mode or normal operation) :
Check the value of current flowing in the laser diode.
1. Remove the upper panel.
2. Read the current printed on the rear side of the optical pick-up.
(Print on the rear side of the optical pick-up)
3. Connect a level meter as shown in Fig. 2
4. Press the ^ key.
Fig.1 Method to push S801
AC2211397
year
version month
A : less than 48 mA
current value
date
line No.shift No.
5. Calculate the current value by the reading of the digital voltmeter.
Reading of the tester (V) Ö 4.7 ( W ) = current value (A)
(Example) Reading of the digital voltmeter of 0.2256 V :
0.2256 V Ö 4.7 W = 0.048 (A) = 48 mA
6. Check that the current value is within the following range.
+5 ¥ Current value of the label -11 mA(25°C)
Variation by temperature : 0.4mA / °C
Current increases with temperature increased.
Current decreases with temperature decreased.
If the current is more than the range above, there is a trouble in the
automatic power control circuit or the laser diode is in deterioration.
If less than the range, a trouble exists in the automatic power control
circuit or the optical pick-up.
[MAIN BOARD] (Conductor side)
S801
TP506
digital voltmeter
TP547
