Page 1
Maintenance
Fuse replacement
When replacing the fuse, be sure to use one
matching the amperage rating stated on the
original fuse. If the fuse blows, check the power
connection and replace the fuse. If the fuse
blows again after replacement, there may be an
internal malfunction. In such a case, consult
your nearest Sony dealer.
Warning
Never use a fuse with an amperage rating
exceeding the one supplied with the unit as this
could damage the unit.
Additional Information
Precautions
- If your car was parked in direct sunlight, allow
the unit to cool off before operating it.
- Power antennas will extend automatically
while the unit is operating.
If you have any questions or problems
concerning your unit that are not covered in this
manual, please consult your nearest Sony dealer.
Moisture condensation
On a rainy day or in a very damp area, moisture
condensation may occur inside the lenses and
display of the unit. Should this occur, the unit
will not operate properly. In such a case, remove
the disc and wait for about an hour until the
moisture has evaporated.
To maintain high sound quality
Be careful not to splash juice or other soft drinks
onto the unit or discs.
Fuse (10 A)
Notes on discs
- To keep the disc clean, do not touch the
surface. Handle the disc by its edge.
- Keep your discs in their cases or disc
magazines when not in use. Do not subject the
discs to heat/high temperature. Avoid leaving
them in parked cars or on dashboards/rear
trays.
- Do not attach labels, or use discs with sticky
ink/residue. Such discs may stop spinning
when used, causing a malfunction, or may ruin
the disc.
- Discs with special shapes (heart-shaped discs,
octagonal discs, etc.) cannot be played on this
unit. Attempting to do so may damage the
unit. Do not use such discs.
- You cannot play 8cm (3in.) CDs.
- Before playing, clean the discs with a
commercially available cleaning cloth. Wipe
each disc from the center out. Do not use
solvents such as benzine, thinner,
commercially available cleaners, or antistatic
spray intended for analog discs.
Notes on CD-R discs
- You can play CD-Rs (recordable CDs)
designed for audio use on this unit.
Look for this mark to distinguish CD-Rs for
audio use.
This mark denotes that a disc is not for audio
use.
- Some CD-Rs (depending on the equipment
used for its recording or the condition of the
disc) may not play on this unit.
- You cannot play a CD-R that is not finalized*.
*A process necessary for a recorded CD-R disc to be
played on the audio CD player.
Removing the unit
1 Insert the supplied tool between the unit
and the frame, and rotate 90° to release
the hidden mounting spring. Repeat on
the opposite side and remove the frame.
2 Insert a flathead screwdriver between the
bracket and mounting spring. Gently pry
the spring toward the unit while pulling
the unit out a little. Repeat on the
opposite side and remove the unit.
90°10 mm (
13/32 in.)
4 mm (
3/16 in.)
Page 2
CDX-L250
SEL
MODE SRC
AT T SENS 1DISC OFFMBP
6 5 4 3 2 BTM DSPL REP SHUF BL SKIP ATA MTL
SEEK
AMS
SOURCE
D-BASSD
Location of controls
1Volume +/-“ button
2MODE button
3SRC (SOURCE) (TUNER/CD) button
4SEL (select) button
5Display window
6
MBP (My Best sound Position) button
7D (D-BASS) button
8Z (eject) button
9Reset button Refer to the pages listed for details.
Radio
The unit can store up to 6 stations per band
(FM1, FM2, FM3, and AM1, AM2).
Caution
When tuning in stations while driving, use Best
Tuning Memory to prevent accidents.
Storing stations
automatically
- Best Tuning Memory (BTM)
The unit selects the stations with the strongest
signals within the selected band, and stores
them in the order of their frequency.
1 Press (SRC) repeatedly to select the
radio.
2 Press (MODE) repeatedly to select the
band.
3 Press (BTM) for 2 seconds.
The unit stores stations in the order of their
frequencies on the number buttons. A beep
sounds when the setting is stored.
Notes
- If only a few stations can be received due to weak
signals, some number buttons will retain their
former settings.
- When a number is indicated in the display, the unit
starts storing stations from the one currently
displayed.
Storing only the desired
stations
You can manually preset the desired stations on
any chosen number button.
1 Press (SRC) repeatedly to select the
radio.
2 Press (MODE) repeatedly to select the
band.
3 Press either side of (SEEK/AMS) to tune in
the station that you want to store.
4 Press the desired number button ((1) to
(6)) until MEM appears.
The number button indication appears in the
display.
Note
If you try to store another station on the same
number button, the previously stored station will be
erased.
CD Player
Playing a disc
Insert the disc (labeled side up).
Playback starts automatically.
If a disc is already inserted, press (SRC)
repeatedly until CD appears to start playback.
To Press
Stop playbackZ or (OFF)
Eject the discZ
Skip tracks(SEEK/AMS) (./>)
-“ Automatic [once for each track]
Music Sensor
Fast-forward/(SEEK/AMS) (m/M)
reverse [hold to desired point]
-“ Manual Search
Note
When the last track on the disc is over, playback
restarts from the first track of the disc.
Display items
When the disc/track changes, any prerecorded
title of the new disc/track is automatically
displayed.
Source
Track number
To Press
Switch display(DSPL)
item
Playing tracks repeatedly
- Repeat Play
The current track will repeat itself when it
reaches the end.
During playback, press (3) (REP)
repeatedly until REP indicator appears
in the display.
Repeat Play starts.
To return to normal play mode, press (3) (REP)
again.
Playing tracks in random
order
- Shuffle Play
You can select to play the tracks on the current
disc in random order.
During playback, press (4) (SHUF)
repeatedly until SHUF indicator appears
in the display.
Shuffle Play starts.
To return to normal play mode, press (4)
(SHUF) again. q;ATT (attenuate) button
qaSENS button
qsNumber buttons
(3)REP
(4)SHUF
qdBTM (Best Tuning Memory) button
qfDSPL (display mode change) button
qgOFF button*
qhSEEK/AMS +/-“ button
*Warning when installing in a car
without an ACC (accessory) position on
the ignition key switch
Be sure to press (OFF) on the unit for 2
seconds to turn off the clock display after
turning off the engine.
Otherwise, the clock display does not turn off
and this causes battery drain.
Displayable items
- Clock
- Elapsed playing time
Quickly attenuating the
sound
Press (ATT).
The ATT indicator appears in the display.
To restore the previous volume level, press
(ATT) again.
Canceling the beep sound
Press (6) while pressing (SEL) down.
To activate the beep sound again, press these
buttons again.
Note
If you connect an optional power amplifier and do
not use the built-in amplifier, the beep sound will be
deactivated.
Other Functions
Adjusting the sound
characteristics
You can adjust the bass, treble, balance, and
fader.
The bass and treble levels can be stored
independently for each source.
1 Select the item you want to adjust by
pressing (SEL) repeatedly.
Each time you press (SEL), the item changes
as follows:
BAS (bass) t TRE (treble) t
BAL (left-right) t FAD (front-rear)
2 Adjust the selected item by pressing
either side of the volume +/-“ button.
Note
Adjust within 3 seconds after selecting the item.
