Page 2
CDX-GT55IP/GT55IPS/GT62IPW/GT620IP
3
1. SERVICE NOTE ..................................................... 4
2. GENERAL
Location of Controls ....................................................... 5
Connections .................................................................... 7
3. DISASSEMBLY
3-1. Sub (AUX) Panel Assy .................................................. 11
3-2. CD Mechanism Block ..................................................... 11
3-3. Main Board ..................................................................... 12
3-4. Servo Board .................................................................... 12
3-5. Chassis (T) Sub Assy ...................................................... 13
3-6. Roller Arm Assy .............................................................. 13
3-7. Chassis (OP) Assy ........................................................... 14
3-8. Chucking Arm Sub Assy ................................................. 14
3-9. Sled Motor Assy .............................................................. 15
3-10. Optical Pick-up Section .................................................. 16
3-11. Optical Pick-up ............................................................... 16
4. DIAGNOSIS FUNCTION ..................................... 17
5. DIAGRAMS
5-1. Block Diagram -Main Section- ..................................... 21
5-2. Block Diagram -Display Section- ................................. 22
5-3. Printed Wiring Board -Main Section- ............................ 24
5-4. Schematic Diagram -Main Section (1/4)- ...................... 25
5-5. Schematic Diagram -Main Section (2/4)- ...................... 26
5-6. Schematic Diagram -Main Section (3/4)- ...................... 27
5-7. Schematic Diagram -Main Section (4/4)- ...................... 28
5-8. Printed Wiring Board -Sub Section- .............................. 29
5-9. Schematic Diagram -Sub Section- ................................. 30
5-10. Printed Wiring Boards -Key Section - ........................... 31
5-11. Schematic Diagram -Key Section - ............................... 32
6. EXPLODED VIEWS
6-1. Main Section ................................................................... 38
6-2. Front Panel Section ......................................................... 39
6-3. CD Mechanism Section (MG-101I-188//Q) ................... 40
7. ELECTRICAL PARTS LIST .............................. 41
TABLE OF CONTENTS
UNLEADED SOLDER
Boards requiring use of unleaded solder are printed with the lead-
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
- Unleaded solder melts at a temperature about 40 °C higher than ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to about 350 °C.
Caution: The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so be careful!
- Strong viscosity
Unleaded solder is more viscous (sticky, less prone to fl ow)
than ordinary solder so use caution not to let solder bridges
occur such as on IC pins, etc.
- Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may also be added to ordinary solder.
This compact disc player is classi
fi ed as a CLASS 1 LASER
product. The CLASS 1 LASER PRODUCT label is located on the
exterior.
CDX-GT55IP/GT55IPS:
This label is located on the bottom of the chassis.
- CD playback You can play CD-DA (also containing CD TEXT) and CD-R/
CD-RW (MP3/WMA/AAC fi les).
Type of discs Label on the disc
CD-DA
MP3
WMA AAC
