Page 1
2
Warning
Warning if your cars ignition has no
ACC position
Be sure to set the Auto Off function (page 8).
The unit will shut off completely and
automatically in the set time after the unit is
turned off, which prevents battery drain.
If you do not set the Auto Off function, press
and hold (OFF) until the display disappears
each time you turn the ignition off.
For installation and connections, see the
supplied installation/connections manual.
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
-“ Reorient or relocate the receiving antenna.-“ Increase the separation between the equipment
and receiver.
-“ Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
-“ Consult the dealer or an experienced radio/TV
technician for help.
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate this
equipment.
The use of optical instruments with this produc t will increase eye hazard. CAUTION
Page 2
3
Table of Contents
Welcome ! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Getting Started
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . 4
Detaching the front panel . . . . . . . . . . . . . . . . . 4
Attaching the front panel . . . . . . . . . . . . . . . 5
Location of controls and basic
operations
Main unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Radio
Storing and receiving stations . . . . . . . . . . . . . . 7
Storing automatically - BTM . . . . . . . . . . . 7
Storing manually . . . . . . . . . . . . . . . . . . . . . . 7
Receiving the stored stations . . . . . . . . . . . . 7
Tuning automatically . . . . . . . . . . . . . . . . . . 7
Other functions
Changing the sound settings . . . . . . . . . . . . . . . 8
Adjusting the balance and fader
- BAL/FAD . . . . . . . . . . . . . . . . . . . . . . . . 8
Customizing the equalizer curve
- EQ lite . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Adjusting setup items - SET . . . . . . . . . . . . . 8
Using optional equipment . . . . . . . . . . . . . . . . . 9
Auxiliary audio equipment. . . . . . . . . . . . . . 9
Additional Information
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Notes on discs . . . . . . . . . . . . . . . . . . . . . . 10
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Removing the unit. . . . . . . . . . . . . . . . . . . . . . 11
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 11
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 12
Error displays/Messages. . . . . . . . . . . . . . . 13
