Page 2
7
BASE UNIT (BU-5BD32A)
4two screws
(PTPWH M2.6) 4two screws
(PTPWH M2.6)
5base unit (BU-5BD32A)
1wire (flat type) (21 core)
(CN101) 6four compression springs (932) 3
2two screws
(PTPWH M2.6)
7holder (BU) assy lever (lifter) BU section
Note: When installing the BU
on the chassis, set the
lever (lifter) in free
position, the gear (U/D)
in UP position, and insert
the shaft into the
groove of gear (U/D).gear (U/D)
b
b
TABLE ASSÕY
Note: When installing the table assy
on the chassis assy, engage
the gear (loading C) with the groove
by looking into the gear through
a hole in the table assy.
qstable assy
9three screws
(BTTP M2.6)q;clamp
e
c
c dd
e
qabracket (guide)
gear
(loading C)
7two screws
(BTTP M2.6)
5screw
(BTTP M2.6)
6bracket (guide) 2two screws
(BTTP M2.6)
1Slide the tray until the screw
that fixes the bracket (guide)
can be seen through a round
hole , in the table assy. 3
8bracket (guide 2)
4wire (flat type)
(6 core) (CN15)
