WARNING
To reduce the risk of fire or electric
shock, do not expose this apparatus
to rain or moisture.
To avoid electrical shock, do not
open the cabinet. Refer servicing to
qualified personnel only.
Batteries or batteries installed
apparatus shall not be exposed to
excessive heat such as sunshine,
fire or the like.
CAUTION
The use of optical instruments with
this product will increase eye
hazard. As the laser beam used in
this Blu-ray Disc/DVD player is
harmful to eyes, do not attempt to
disassemble the cabinet.
Refer servicing to qualified
personnel only.
This label is located on the laser
protective housing inside the
enclosure.
This symbol is
intended to alert the
user to the presence
of uninsulated
dangerous voltage
within the products enclosure that
may be of sufficient magnitude to
constitute a risk of electric shock to
persons.
This symbol is
intended to alert the
user to the presence
of important
operating and
maintenance (servicing)
instructions in the literature
accompanying the appliance.
CAUTION
You are cautioned that any
changes or modifications not
expressly approved in this manual
could void your authority to
operate this equipment.
The shielded Interface cable
(Network cable) must be used with
the equipment in order to comply
with the limits for a digital device
pursuant to Subpart B of Part 15 of
FCC Rules.
bThis equipment has been tested
and found to comply with the
limits for a Class B digital device,
pursuant to Part 15 of the FCC
Rules. These limits are designed to
provide reasonable protection
against harmful interference in a
residential installation. This
equipment generates, uses, and can
radiate radio frequency energy
and, if not installed and used in
accordance with the instructions,
may cause harmful interference to
radio communications. However,
there is no guarantee that
interference will not occur in a
particular installation. If this
equipment does cause harmful
interference to radio or television
reception, which can be
determined by turning the
equipment off and on, the user is
encouraged to try to correct the
interference by one or more of the
following measures:
-“ Reorient or relocate the
receiving antenna.
-“ Increase the separation between
the equipment and receiver.
-“ Connect the equipment into an
outlet on a circuit different from
that to which the receiver is
connected.
-“ Consult the dealer or an
experienced radio/TV technician
for help.
Precautions
To prevent fire or shock hazard,
do not place objects filled with
liquids, such as vases, on the
apparatus.
Install this unit so that the AC
power cord can be unplugged
from the wall socket
immediately in the event of
trouble.Owners Record
The model and serial numbers are
located at the rear of the unit.
Record the serial number in the
space provided below. Refer to
them whenever you call upon your
Sony dealer regarding this product.
Model No. BDP-BX1
Serial No.______________
For customers in the U.S.A
If this product is not working
properly, please call 1-800-222-
7669.
For Customers in Canada
If this product is not working
properly, please call 1-877-602-
2008 for Peace of Mind
Warranty Replacement
service.
For other product related questions
please contact our Customer
Information Service Center at
1-877-899-7669 or write to us at:
Customer Information Service 115
Gordon Baker Road, Toronto,
Ontario, M2H 3R6
Page 2
3
Notes About the Discs
To keep the disc clean, handle
the disc by its edge. Do not
touch the surface.
Dust, fingerprints, or scratches
on the disc may cause it to
malfunction.
Do not expose the disc to
direct sunlight or heat sources
such as hot air ducts, or leave it
in a car parked in direct
sunlight as the temperature
may rise considerably inside
the car.
After playing, store the disc in
its case.
Clean the disc with a cleaning
cloth. Wipe the disc from the
center out.
Do not use solvents such as
benzine, thinner,
commercially available disc/
lens cleaners, or anti-static
spray intended for vinyl LPs.
If you have printed the discs
label, dry the label before
playing.
Do not use the following discs.
-“ A disc that has a non-
standard shape (e.g., card,
heart).
-“ A disc with a label or sticker
on it.
-“ A disc that has cellophane
tape or sticker adhesive on it.
Do not resurface the playing
side of a disc to remove
surface scratches. Precautions
On safety To prevent fire or shock
hazard, do not place objects
filled with liquids, such as
vases, on the player, or place
the player near water, such as
near a bathtub or shower room.
Should any solid object or
liquid fall into the cabinet,
unplug the player and have it
checked by qualified
personnel before operating it
any further.
Do not touch the AC power
cord with wet hands. Doing so
may cause an electric shock.
On placement Place the player in a location
with adequate ventilation to
prevent heat build-up in the
player.
Do not place the player on a
soft surface such as a rug that
might block the ventilation
holes.
Do not install this player in a
confined space, such as a
bookshelf or similar unit.
Do not place the player in a
location near heat sources, or
in a place subject to direct
sunlight, excessive dust, or
mechanical shock.
If the player is brought directly
from a cold to a warm location,
or is placed in a very damp
room, moisture may condense
on the lenses inside the player.
Should this occur, the player
may not operate properly. In
this case, remove the disc and
leave the player turned on for
about half an hour until the
moisture evaporates.
Do not install the player in an
inclined position. It is
designed to be operated in a
horizontal position only.
Keep the player and the discs
away from equipment with
strong magnets, such as
microwave ovens, or large
loudspeakers. Do not place heavy or unstable
objects on the player.
Do not place any objects other
than discs on the disc tray.
Doing so may cause damage to
the player or the object.
When you move the player,
take out any discs. If you
dont, the disc may be
damaged.
When you move the player,
disconnect the AC power cord
and all other cables from the
player.
On power sources
The player is not disconnected
from the AC power source as
long as it is connected to the
wall outlet, even if the player
itself has been turned off.
If you are not going to use the
player for a long time, be sure
to disconnect the player from
the wall outlet. To disconnect
the AC power cord, grasp the
plug itself; never pull the cord.
Observe following points to
prevent the AC power cord
being damaged. If the AC
power cord is damaged, it may
result in a fire or an electric
shock.
-“ Do not pinch the AC power
cord between the player and
wall, shelf, etc.
-“ Do not put anything heavy
on the AC power cord or pull
on the AC power cord itself.
On adjusting volumeDo not turn up the volume while
listening to a section with very
low level inputs or no audio
signals. If you do, the speakers
may be damaged when a peak
level section is played.
On cleaningClean the cabinet, panel, and
controls with a soft cloth slightly
moistened with a mild detergent
solution. Do not use any type of
abrasive pad, scouring powder
or solvent such as alcohol or
benzine.
,continued
Page 63
64
Specifications
System
Laser: Semiconductor laser
Inputs and outputs
(Jack name:
Jack type/Output level/Load impedance)
LINE OUT R-AUDIO-L:
Phono jack/2 Vrms/10 kilohms
DIGITAL OUT (OPTICAL):
Optical output jack/-“18 dBm
(wave length 660 nm)
DIGITAL OUT (COAXIAL):
Phono jack/0.5 Vp-p/75 ohms
HDMI OUT:
HDMI 19-pin standard connector
COMPONENT VIDEO OUT
(Y, P
B, PR):
Phono jack/Y: 1.0 Vp-p/
P
B, PR: 0.7 Vp-p/75 ohms
LINE OUT VIDEO:
Phono jack/1.0 Vp-p/75 ohms
LINE OUT S VIDEO:
4-pin mini DIN/
Y: 1.0 Vp-p, C: 0.286 Vp-p/75 ohms
LAN (100):
100BASE-TX Terminal
EXT:
External memory slot (For connecting the
external memory)
DC output: 5 V 500 mA Max
General
Power requirements:
120 V AC, 60 Hz
Power consumption:
26 W
Dimensions (approx.):
430 mm × 220 mm × 60 mm
(17 in. × 8
3/4 in. × 2 3/8 in.)
(width/depth/height) incl. projecting parts
Mass (approx.):
2.9 kg (6
3/8 lb)
Operating temperature:
5 ºC to 35 ºC (41 °F to 95 °F)
Operating humidity:
25 % to 80 %
Supplied accessories
See page 13.
Specifications and design are subject to
change without notice.
