AZ-RS1/RS128
This section is extracted from
instruction manual.
GENERAL
Locating controls
1Display2ÒpavitÓ slot3./> (SKIP/DOWN/UP) buttons4Nx* (PLAY/STOP)/POWER button5VOL (volume) Ð/+* buttons6PRESET button7MENU button8i (headphones) jack9TUNER* button
Player (front/side) Player (rear)
PRESET
TUNER
MENU
2345 1
8 67 9
VOL
POWERDOWNTUNEUP
HOLD
BEEPOFF
REP1SHUFOFF
M.D.S.EON ONOFF
0qa
qs qd
0HOLD/BEEP switchqaREP1 (repeat 1)/SHUF (shuffle) switchqsM.D.S.E (MP3 Digital Sound Enhancer)
switch
qdClip
*The button has a tactile dot.
Display
86 7
23 4 5 1
1ÒpavitÓ insertion indicator : The ÒpavitÓ is inserted in the player
correctly.
: The ÒpavitÓ is not inserted in the
player.
2Operation status indication Displays the icon for music data
playback, radio, stopwatch or countdown
timer.
3Play mode indication : Playing all tracks in random order: Playing a track repeatedly
Ò Ó is displayed in the radio preset
mode.
4M.D.S.E indication Displayed only during music data
playback.
Ò Ó is displayed in the radio preset
mode.
5Volume indication Roughly shows the current volume level. 6Battery level indication Roughly shows the remaining power of
the battery. If Ò Óflashes, the battery is
depleted.
7Character information display Displays the title, file name of music
data, etc.
During radio reception, displays the band
and frequency.
8Track number/elapsed playing time
indication
Displays the preset numbers in the radio
preset mode.
