AZ-BS1/BS32
PARTS LIST
Ref. No. Part No. Description Remark
1X-2021-660-1 MAIN ASSY (SERVICE) (CE7) (AZ-BS1)
1X-2021-662-1 MAIN ASSY (SERVICE) (U) (AZ-BS32)
24-253-386-01 COVER (HP)
3A-4715-331-A LID BLOCK ASSY, BATTERY CASE
44-253-371-01 PAVIT LID
54-253-372-01 HOLDER (BATTERY CASE LID)
64-253-388-01 PACKING (PAVIT)
74-254-822-01 SHAFT (LID)
83-254-022-01 SCREW
9not supplied MEMORY, USB AZ-RM32 (AZ-BS32 only)
10 4-252-295-01 CD-ROM (Music Transfer pavit Edition)
11 X-2022-450-1 WIRE (ANTENNA) ASSY
4-253-596-11 MANUAL INSTRUCTION (M-T)
(Music Transfer pavit Edition) (ENGLISH)
4-253-596-21 MANUAL INSTRUCTION (M-T)
(Music Transfer pavit Edition)
(FRENCH, SPANISH, PORTUGUESE) (AZ-BS1)
4-253-596-31 MANUAL INSTRUCTION (M-T)
(Music Transfer pavit Edition)
(GERMAN, DUTCH, ITALIAN) (AZ-BS1)
4-254-827-11 MANUAL, INSTRUCTION (ENGLISH)
4-254-827-21 MANUAL, INSTRUCTION (FRENCH, SPANISH)
(AZ-BS1)
4-254-827-31 MANUAL, INSTRUCTION
(GERMAN, DUTCH, ITALIAN) (AZ-BS1)
4-255-100-01 STRAP USB memory player with FM radio (1)
9 USB storage media pavit* (1)
(not supplied)
10 CD-ROM (Music Transfer pavit Edition) (1)
11 FM wire antenna (1)* Supplied with AZ-BS32 only.
1
4
6
8
8
8
2 7
7
5
73
Notes:
The part name in a figure has indicated the name currently used by instruction
manual.
