Basic Setup
Figure 1 illustrates the basic AuxPander setup.
The AuxPander connects to the mixing console insert points. Any processors that were connected to the mixing con-
sole inserts are moved to the AuxPander INSERT jacks.
The mixing console receives the same signal as in the original setup, including the processed signal from the mono
and stereo processors. Eight additional auxiliary outputs are available at the AuxPander OUTPUT jacks.
NOTE: For details on how to use insert points, including what type of cables to use, see Appendix II, Fundamentals of
Insert Points on Page 16 of this manual.
Original Mixing Console Setup
Channel Insert Points
IN/OUT Jacks
8 AuxPander
Outputs Mixing Console with AuxPander
8 Channel 1/4
Phone TRS-TRS
Snake Cable*
* NOTE: Eight-channel 1/4 TRS-“TRS snakes are easily obtained and make connecting the AuxPander to a mixer especially neat and easy.
INSERT Jacks
Channel Insert Points
Channel Inputs
Mono Processor
Stereo Processor
Mono Processor
Stereo Processor
Channel Inputs
OUTPUT Jacks
BASIC SETUP
FIGURE 1
