ENGLISH
2
Introduction
: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
This symbol is intended to alert the user to \0the presence of
uninsulated "dangerous voltage" within the product'\0s
enclosure that may be of sufficient magnitude to \0constitute
a risk of electric shock to persons.This symbol is intended to alert the user to \0the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the applia\0nce.
Caution regarding installation
Note : For heat dispersal, do not install this unit in a confined space such as a bookcase or similar enclosure.
Be sure to leave a space around this unit equal to, or greater than, shown below.
Left, right and rear sides : 20 cm, top side : 40 cm
: TO REDUCE THE RISK OF ELECTRIC SHOC\0K, DO NOT REMOVE COVER (OR BACK). \0
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL. CAUTION
WARNING
Do not block ventilation openings or stack other\2 equipment on the top.
READ THIS BE\bORE OP\KERATING YOUR UNIT
D 6 5
CAUTION
FOR YOUR SAFETY
Units shipped to Australia are designed for operation on 230 V AC only.
To ensure safe operation, the three-pin plug supplied must be inserted only into a standard three-pin power point
which is effectively earthed through the normal household wiring. Extension cords used with the equipment must
be three-core and be correctly wired to provide connection to earth.
Improper extension cords are a major cause of fa\0talities. The fact that the equipment operates s\0atisfactorily
does not imply that the power point is earthed \0and that the installation is completely safe. Fo\0r your safety, if
in any doubt about the effective earthing of the\0 power point, consult a qualified electrician.
PAN-EUROPEAN UNIFIED VOLTAGE
All units are suitable for use on supplies 2\020-240 V AC.
EUROPE
AUSTRALIA 220 V \b
240 V
- Leave a space around the unit for sufficient ven\0tilation.
- Avoid installation in extremely hot or cold loca\0tions, or in an area
that is exposed to direct sunlight or heating \0equipment.
- Keep the unit free from moisture, water, and d\0ust.
- Do not let foreign objects in the unit.
- The ventilation should not be impeded by covering \0the ventilation
openings with items, such as newspapers, table-clot\0hs, curtains,
etc.
- No naked flame sources, such as lighted candles,\0 should be
placed on the unit.
- Please be care the environmental aspects of battery\0 disposal.
- The unit shall not be exposed to dripping or \0splashing for use.
- No objects filled with liquids, such as vases, \0shall be placed on
the unit.
- Do not let insecticides, benzene, and thinne\0r come in contact with the set .
- Never disassemble or modify the unit in any way\0.
Notes on the AC power cord and the wall \0outlet.
- The unit is not disconnected from the AC p\0ower source(mains)
as long as it is connected to the wall outlet\0, even if the unit has
been turned off.
- To completely disconnect this product from the main\0s,
disconnect the plug from the wall socket outlet.\0
- When setting up this product, make sure that th\0e AC outlet you
are using is easily accessible.
- Disconnect the plug from the wall outlet when \0not using the unit
for long periods of time.
Information for Users on Collection and Disp\2osal of
Old Equipment and used Batteries
These symbols on the products, packaging, and\for
accompanying documents mean that used electrical
and electronic products and batteries should not be\0
mixed with general household waste. For proper
treatment, recovery and recycling of old products \0and
used batteries, please take them to applicable
collection points, in accordance with your national
legislation.
By disposing of these products and batteries cor\0rectly,
you will help to save valuable resources and pre\0vent
any potential negative effects on human health and \0the
environment which could otherwise arise from
inappropriate waste handling.
For more information about collection and recycling \0of
old products and batteries, please contact your lo\0cal
municipality, your waste diposal service or the po\0int of
sale where you purchased the items.
[Inform\ftion on Dis\bpos\fl in other Coun\btries outside the
Europe\fn Union]
These symbols are only valid in the European Uni\0on. If
you wish to discard these items, please contact \0 your
local authorities or dealer and ask for the corr\0ect
method of diposal.
\bote for the b\fttery symbol (bottom two symbol ex\fmples):
The sign Pb below the symbol for batteries indic\0ates
that this batteries contains lead.
Page 2
3
ENGLISH
CONTENTS
Introduction- READ THIS BEFORE OPERATING YOUR UNIT | 2
System Connections | 4
Front Panel Controls | \f0
Remote Controls | \f2 - REMOTE CONTROL OPERATION RANGE | \f3
- LOADING BATTERIES | \f3
Operations - LISTENING TO A PROGRAM SOURCE | \f4
- SURROUND SOUND | \f6
- ENJOYING SURROUND SOUND | \f7
- LISTENING TO RADIO BROADCASTS | 22
- LISTENING TO RDS BROADCASTS(FM \0ONLY) | 24
(RDS Tuner(Regional Option for some countries \0in Europe, etc.))
- RECORDING | 26
- OTHER FUNCTIONS | 27
- CONFIRMING THE HDMI FUNCTION | 28
System Setup | 29 - SETTING THE SYSTEM | 3\f
- SETTING THE INPUT | 33
- SETTING THE SPEAKER SETUP | 34
- SETTING THE CH LEVEL | 38
- SETTING THE PARAMETER | 40
- SETTING THE HDMI | 42
Troubleshooting Guide | 44
Specifications | 45
