Page 2
3
Fig. 1. Rear Panel of LDS16-45 With Eight Zones
Fig. 2. Rear Panel of LDS12-60 With Six Zones - 3 and 6 are not operative
defeat the safety provided by the polarized AC plug.
If the plug should fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the safety
purpose of the grounding-type plug. If you use this
product in a country which only has two slotted
receptacles in the house, you must use a three-pin
adapter plug to earth ground which is the E (earth
pin) of the power cord connected to this product.
3. Do not overload wall outlets, extension or integral
convenience receptacles, as this could result in a risk
of fire or shock.
Operating Voltage
The LDS16-45 and LDS12-60 amplifier is factory-set
for 110V/120V 60 HZ or 230V 50HZ AC operation,
according to the country for which the unit was
manufactured (230V in European Union countries, in
compliance with CE regulations). The operating voltage
cannot be changed by the user and any attempt to do somay risk of causing damage to the amplifier and will
void the warranty.
Care of the Product
Clean the product by dusting with a dry cloth. Do not
permit objects of any kind to be pushed and/or fall into
the product through the enclosure openings.
Front Panel Description
The front panel houses the main Power ON/OFF
switch. A blue power LED will illuminate when the
LDS16-45/12-60 is ON and will dim when all zone
amplifiers are in the Standby mode. The LED will
only extinguish when the Power ON/OFF switch is in
the OFF position or when the LDS16-45/12-60 is
disconnected from the electrical outlet.
Rear Panel Connections
The LDS16-45/12-60 has been designed to provide
multiple stereo zones with identical performance and
