FEATURES AND SPECIFICATIONS: LDS 16-40
- Full-width four inch high rack-mountable chassis
- Elegantly sculptured front panel has a master power switch with blue LED
- Total of thirty-two discrete output devices
- Two hefty 775 VA quadruple tapped dual voltage transformers so that each zone is allocated
its own specific share of the transformers to ensure that all channels will have identical
output capability
- Eight large aluminum heat-sinks for a cool fan-free operation
- Outputs 80/120 watts per zone into 8/4 ohms respectively with all channels driven
- Rear panel includes RCA inputs, a simple bus system for use when adjacent zones will have
the same music, gain controls, stereo/mono switches, 12 volt triggers and eight sets of
removable speaker connectors
- Removable power cord
- Patent-pending circuitry that will automatically check for short circuits and then measure
the impedance of the intended speaker load before connecting it to the amplifier. This test of
impedance helps to ensure that the load is within the required specification and so will not
cause excessive distortion, overheating or long-term reliability problems
SPECIFICATIONS:
Carton weight 66 lbs/32 kilograms
Rated Power 40 watts per channel @ 8 ohms and 60 watts/channel @ 4
ohms with no more than 0.1% THD from 20 Hz-“20KHz
all channels driven
Power Bandwidth 10Hz-“75KHz
Gain 30dB
Signal to Noise Ratio 91dB/wide band, 91dB/A weighted
Line Input Impedance 22 K ohms
Line Level Sensitivity 950 Mv
Dynamic Headroom 1.3 dB
Power Supply 110v/60Hz or 220v/50Hz
Dimensions 17.7" W x 18.2" D x 7"H
450mm W x 462mm D x 177mm H
SHERBOURN TECHNOLOGIES INC.
19/3A Sterling Road - North Billerica, MA 01862 USA
Tel: 978-663-7385 Fax: 978-663-7389
www. Sherbourn.com
In accordance with our policy of continual improvement, we reserve the right to change the specifications without notice.
Printed in the USA.
