Extracted text from sharp md x 5 owners manual (Ocr-read)
Page 1
1
12Outdoor Antenna Grounding - If an outside antenna is connected to the
receiver, be sure the antenna system is grounded so as to provide some
protection against voltage surges and built-up static charges. Article
810 of the National Electrical Code, ANSI/NFPA 70, provides informa-
tion with regard to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna discharge unit,
size of grounding conductors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements for the ground-
ing electrode.
13Non use Periods - The power cord of the appliance should be unplugged
from the outlet when left unused for a long period of time.
14Object and Liquid Entry - Care should be taken so that objects do not
fall and liquids are not spilled into the enclosure through openings.
15Damage Requiring Service - The appliance should be serviced by
qualified service personnel when:
AThe power-supply cord or the plug has been damaged; or
BObjects have fallen, or liquid has been spilled into the appliance; or
CThe appliance has been exposed to rain; or
DThe appliance does not appear to operate normally or exhibits a marked
change in performance; or
EThe appliance has been dropped, or the enclosure damaged.
16Servicing - The user should not attempt to service the appliance beyond
that described in the operating instructions. All other servicing should be
referred to qualified service personnel.
17Grounding or Polarization - Precautions should be taken so that the
grounding or polarization means of an appliance is not defeated. 1Heed Warnings - All warnings on the appliance and in the operating
instructions should be adhered to.
2Follow Instructions - All operating and use instructions should be
followed.
3Water and Moisture - The appliance should not be used near water
- for example, near a bathtub, washbowl, kitchen sink, laundry tub,
in a wet basement, or near a swimming pool, etc.
4Carts and Stands - The appliance should be used only with a cart
or stand that is recommended by the manufacturer.
¥ An appliance and cart combination should be
moved with care.
Quick stops, excessive force, and uneven sur-
faces may cause the appliance and cart combina-
tion to overturn.
5Wall or Ceiling Mounting - The appliance should be mounted to a
wall or ceiling only as recommended by the manufacturer.
6Ventilation - The appliance should be situated so that its location or
position does not interfere with its proper ventilation. For example,
the appliance should not be situated on a bed, sofa, rug, or similar
surface that may block the ventilation openings; or, placed in a built-
in installation, such as a bookcase or cabinet that may impede the
flow of air through the ventilation openings.
7Heat - The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances
(including amplifiers) that produce heat.
8Power Sources - The appliance should be connected to a power
supply only of the type described in the operating instructions or as
marked on the appliance.
9Power-Cord Protection - Power-supply cords should be routed so
that they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit from the
appliance.
10 Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
11Power Lines - An outdoor antenna should be located away from
power lines.
ANTENNA LEAD IN
WIRE
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)GROUND CLAMPSGROUNDING CONDUCTORS
(NEC SECTION 810-21)ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20) EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
NEC - NATIONAL ELECTRICAL CODE
S2898A
IMPORTANT SAFEGUARDS
CAUTION
All the safety and operating instructions should be read before the
appliance is operated, and should be retained for future reference.
Electrical energy can perform many useful functions. This unit has
been engineered and manufactured to assure your personal safety.
Improper use can result in potential electrical shock or fire hazards. In
order not to defeat the safeguards, observe the following basic rules for
its installation, use and servicing.
FOR YOUR RECORDS
For your assistance in reporting this unit in case of loss or theft, please record below the model number and serial number which are located on the
rear of the unit.
Please retain this information.
Model number
Serial number
Date of purchase
Place of purchase
SPECIAL NOTES
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR
BACK).
NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL. The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended
to alert the user to the presence of
uninsulated Òdangerous voltageÓ within
the productÕs enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION
RISK OF
ELECTRICSHOCK
DONOT
OPEN
*01-2198.6.23, 10:09 AM 1
Page 2
2
Note:
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruc-
tions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
IReorient or relocate the receiving antenna.
IIncrease the separation between the equipment and receiver.
IConnect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
IConsult the dealer or an experienced radio/TV technician for help.WARNING
FCC Regulations state that any unauthorized changes or modifications to
this equipment not expressly approved by the manufacturer could void the
userÕs authority to operate this equipment.
SPECIAL NOTES FOR FCC COMPOSITE DEVICE:
This device is a composite system. The digital device component may not
cause harmful interference.
IIt is the intent of Sharp that this product be used in full compliance with
the copyright laws of the United States and that prior permission be
obtined from copyright owners whenever necessary.
(Continued)
Caution - use of controls or adjustments or
performance of procedures other than those
specified herein may result in hazardous radiation
exposure. WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
0001
PRECAUTIONS0002
H HH H
HGeneral
IDo not use oil, solvents, gasoline, paint thinner or insecticides on
the unit.
IDo not expose the unit to moisture, to temperatures higher than
140¡F (60¡C) or to extreme low temperatures.
IKeep the unit away from direct sunlight, strong magnetic fields,
excessive dust, humidity and electronic/electrical equipment (home
computers, facsimiles, etc.) which generates electrical noise.
IHold the AC power plug by the head when removing it from the AC
outlet, since pulling the cord can damage internal wires.
IUse the unit on a firm, level surface free from vibration.
IIf the unit does not work properly while in use, press the POWER
button to turn the power off, then disconnect the AC power cord from
the AC outlet. Plug the AC power cord back in, and then press the
POWER button to turn the power on.
IIf an electrical storm is taking place near you, it is suggested that
you disconnect the AC power cord from the AC outlet for safety.
IBefore moving the unit, be sure to remove all CDs and MDs from the
unit. Then, turn the power off and unplug the AC power cord.
If you move the unit with CDs or MDs left in it, they may jam inside
the unit, leading to damage.
Warning:
The voltage used must be the same as that specified on this unit. Using
this product with a higher voltage than that which is specified is
dangerous and may result in a fire or other type of accident causing
damage. SHARP will not be held responsible for any damage resulting
from use of this unit with a voltage other than that which is specified.
H HH H
HVolume control
The sound level at a given volume setting depends on a combination
of speaker efficiency, location and many other factors.
It is advisable to avoid exposure to high volume levels, which occur
while turning the unit on with the volume control setting up high, or while
continually listening at high volumes.
H HH H
HCondensation
Sudden temperature changes and storage or operation in an extremely
humid environment may cause condensation inside the cabinet.
Condensation can cause the unit to malfunction.
Follow the procedure below to eliminate condensation.
I II I
ICD and MD pickups
Leave the power on with no disc in the unit until normal playback is possible
(about 1 hour).
I II I
IRemote control
Wipe off any condensation on the transmitter LED with a soft cloth before
operating the unit.
H HH H
HCare of compact discs
Compact discs are fairly resistant to damage, however mistracking can
occur due to an accumulation of dirt on the disc surface.
Follow the guidelines below for maximum enjoyment from your CD collec-
tion and player.
IDo not write on either side of the disc, particularly the non-label side.
Signals are read from the non-label side. Do not mark on this surface.
IKeep your discs away from direct sunlight, heat, and excessive mois-
ture.
IAlways hold CDs by the edges. Fingerprints, dirt, or water on the CDs
can cause noise or mistracking. If a CD is dirty or does not play properly,
clean it with a soft, dry cloth, wiping straight out from the center, along
the radius.
US and foreign patents licensed from Dolby Laboratories Licensing Corpo-
ration.
