Sharp cd xp 200h names of parts

This is the 2 pages manual for sharp cd xp 200h names of parts.
Read or download the pdf for free. If you want to contribute, please mail your pdfs to info@audioservicemanuals.com.

Page: 1 / 2
left right
sharp cd xp 200h names of parts

Extracted text from sharp cd xp 200h names of parts (Ocr-read)

Page 1

Ð 5 Ð CD-XP200H Remote control 1. Remote Control Transmitter 2. On/Stand-by Button 3. Disc Number Select Buttons 4. CD Random Button 5. CD Memory Button 6. Tape 2 Record Pause Button 7. CD Track Down or Fast Reverse, Tape 2 Rewind Button 8. CD or Tape Stop Button 9. Tuner (Band) Button 10. CD Button 11. Video/Auxiliary Button 12. Extra Bass Button 13. Equaliser Mode Select Button 14. CD Clear Button 15. Tuner Preset Up and Down Buttons 16. CD Pause Button 17. CD Track Up or Fast Forward, Tape 2 Fast Forward Button 18. CD Play or Repeat, Tape Play Button 19. Tape (1 2) Button 20. Volume Up and Down Buttons 1 2 3 4 5 6 7 8 9 10 11 12 15 16 17 18 19 13 14 20 Buttons with " " mark in the illustration can be operated on the remote control only. 1. Tweeter 2. Woofer 3. Bass Reflex Duct 4. Speaker Wire 1 3 3 4 2 CD-XP200H CP-XP200H
