sharp cd pc 4900

Extracted text from sharp cd pc 4900 (Ocr-read)

Page 1

CD-PC4900 Ð 2 Ð TiNSE0237AWZZ J TiNSE0246AWZZ J Operation Manual [For U.S.A.] AE TiNSZ0398AWZZ J TiNSZ0414AWZZ J Operation Manual [For Central America] TiNSZ0404AWZZ J TiNSZ0470AWZZ J Quick Guide [For U.S.A. Only] 202 92LCAB3051AS1 J 92LCAB3052AS1 J Front Panel Ass'y BC 202-1 ÐÐÐÐÐÐÐÐÐÐ ÐÐÐÐÐÐÐÐÐÐ Front Panel (Not Replacement Item) ÐÐ 202-2 JKNBZ0557AWSA J Same as CD-PC672 Button,Disc No. AE 202-3 JKNBZ0558AWSA J Same as CD-PC672 Button,Open/Close/Disc Skip AE 202-4 JKNBZ0559AWSA J Same as CD-PC672 Button,Power AE 202-5 JKNBZ0560AWSA J Same as CD-PC672 Button,X-BASS/Demo AE 202-6 JKNBZ0563AWSA J JKNBZ0563AWSB J Button,FF/REW/Tuning AG 202-7 JKNBZ0565AWSA J Same as CD-PC672 Button,Timer/Sleep/Clock AD 202-8 JKNBZ0570AWSA J Same as CD-PC672 Button,Dimmer/Equalizer AD 202-9 JKNBZ0601AWSA J Same as CD-PC672 Button,Dolby Pro Logic AE 202-10 KNOB3051AASY1 J Same as CD-PC672 Button, Function AK 202-11 HDECQ0412AWSA J Same as CD-PC672 Operation Ring A AC 202-12 HDECQ0413AWSA J HDECQ0413AWSB J Operation Ring B AB 202-13 HEDCQ0414AWSA J Same as CD-PC672 Cap,Operation Center AD 202-14 HDECQ0415AWSA J Same as CD-PC672 Cover,LED AD 202-15 HDECQ0417AWSA J Same as CD-PC672 Panel,Center Cap AE 202-16 HDECQ0418AWSA J HDECQ0418AWSD J Panel,Decoration AG 202-17 HDECQ0419AWSA J Same as CD-PC672 Decoration,Play Button AF 202-18 HDECQ0420AWSA J Same as CD-PC672 Decoration,Stop Button AE 202-19 HDECQ0455AWSA J Same as CD-PC672 Panel,AMP AH 202-20 HDECQ0457AWSA J Same as CD-PC672 Panel,Play Decoration AC 202-21 HDECQ0458AWSA J Same as CD-PC672 Panel,Stop Decoration AC 202-22 MLIFP0006AWZZ J Same as CD-PC672 Damper,Cassette Holder AE 202-23 PSHEP0031AWZZ J Same as CD-PC672 Sheet,Reflector AC 203 92LMEC3051CTS1 J 92LMEC3052CTS1 J Cassette,Holder Ass'y,Tape 1 AL 203-1 ÐÐÐÐÐÐÐÐÐÐ Same as CD-PC672 Cassette Holder,Tape 1 (Not Replacement Item) ÐÐ 203-2 GCoVA1221AWSB J GCoVA1221AWSC J Cassette Cover,Tape 1 203-3 HDECQ0408AWSA J Same as CD-PC672 Panel,Cassette,Tape 1 AD 204 92LMEC3051CTS2 J 92LMEC3052CTS2 J Cassette,Holder Ass'y,Tape 2 AL 204-1 ÐÐÐÐÐÐÐÐÐÐ Same as CD-PC672 Cassette Holder,Tape 2 (Not Replacement Item) ÐÐ 204-2 GCoVA1222AWSB J GCoVA1222AWSC J Cassette Cover,Tape 2 204-3 HDECQ0409AWSA J Same as CD-PC672 Panel,Cassette Tape 2 AD DIFFERENCE BETWEEN CD-PC672 AND CD-PC4900 CODE DESCRIPTION PART NO. REF. NOPART NO. CD-PC672 CD-PC4900 CABINET PARTS ACCESSORIES PARTS Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the safety and performance of the set. ! MARK: SPARE PARTS-DELIVERY SECTION 905 92L33-01-0940 J 92L33-01-0960 J Label,Parts Code SPEAKER BOX PARTS REAR SPEAKER

Page 2

CD-PC4900 Ð 3 Ð A B C D E F G H 1 23 45 6 NO. PARTS CODE PRICE RANK DESCRIPTION CP-C4900 SPEAKER BOX PARTS FRONT SPEAKER 901 92L10002290010 J BD Cabinet AssÕy 902 92L200L0290010 J AU Front Panel,Left 903 92L200R0290010 J AU Front Panel,Right 904 92L201L0290010 J AR Net Frame AssÕy,Left 905 92L201R0290010 J AR Net Frame AssÕy,Right 906 92L3141PC46210 J AL Speaker Cord AssÕy (With Capacitor) 907 92L44210310100 J AD Cushion Wire 908 92LPCAT1XL12 J AC Catching Holder 909 411-B930100P1 J Screw,¿3´10mm 910 92L44010213300 J AH Port Cushion 911 411-B840140B1 J Screw,¿4´14mm 912 92L6000C490000 J Label,Specifications SP1,2 VSP0013WK396A J Woofer SP3,4 VSP0050TB256A J Tweeter SP5,6 92L303R0300110 J AN Super Tweeter 904,905 908x2 908x2 SP3,4 909x2 907 SP1,2 911x4 910(with Capacitor C1,2) C1,2 Capacitor 912 909x2 906 SP5,6 902,903 901 SUPER TWEETER SP5(L-CH) SP6(R-CH) TWEETER SP3(L-CH) SP4(R-CH) WOOFER SP1(L-CH) SP2(R-CH)SUPER TWEETER SP5(L-CH) SP6(R-CH) TWEETER SP3(L-CH) SP4(R-CH) WOOFER SP3(L-CH) SP4(R-CH) C1,2 Capacitor 2.2µF,50V, Electrolytic (N.P.) BK YE BK BKRED RED Figure 3 SPEAKER EXPLODED VIEW (1/2)
