CD-C405W/CD-C420H/CP-C410/CP-C405/CP-SR421
Ð 2 Ð
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
General
Power source:AC 110/127/220/230 - 240 V, 50/60 Hz
(CD-C405W)
Power source:AC 230 V, 50 Hz
(CD-C420H)
Power consumption:65 W
Dimensions:Width; 270 mm (10-5/8")
Height; 300 mm (11-13/16")
Depth; 359.5 mm (14-3/16")
Weight:5.0 kg (11.0 lbs.)
Amplifier section
Output power:PMPO; 160 W (total)
MPO; 34 W (17 W + 17 W)(10 % T.H.D.)
RMS; 20 W (10 W + 10 W)(10 % T.H.D.)
Output terminals:Speakers; 8 ohms
(CD-C405W)Headphones; 16-50 ohms
(recommended; 32 ohms)
Output terminals:Front speakers; 8 ohms
(CD-C420H)Rear speakers; 16 ohms
Headphones; 16-50 ohms
(recommended; 32 ohms)
Input terminals:Video/Auxiliary (audio signal);
245 mV/47 kohms
Tuner section
Frequency range:FM; 88 - 108 MHz
(CD-C405W)AM; 531 - 1,602 kHz
Frequency range:FM; 87.5 - 108 MHz
(CD-C420H)AM; 522 - 1,620 kHz
Compact disc player section
Type:3-disc multi-play compact disc player
Signal readout:Non-contact, 3-beam semi-con-ductor
laser pickup
D/A Converter:1-bit D/A converter
Frequency response:20 - 20,000 Hz
Dynamic range:90 dB (1 kHz)
Cassette deck section
Frequency response:50 - 14,000 Hz (Normal tape)
Signal/noise ratio:55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/playback)
Wow and flutter:0.15 % (WRMS)
CD-C405W/CD-C420H
Speaker section
Type:2-way type [10 cm (4") woofer and super
tweeter]
Maximum input power:20 W
Impedance:8 ohms
Dimensions:Width; 180 mm (7-1/8")
Height; 300 mm (11-13/16")
Depth; 214 mm (8-7/16")
Weight:2.4 kg (5.3 lbs.)/each
Front speaker section
Frequency response:100 MM (4") full-range speaker
Maximum input power:20W
Impedance:8 ohms
Dimensions:Width; 180 mm (7-1/8")
Height; 300 mm (11-13/16")
Depth; 204 mm (8")
Weight:2.1 kg (4.6 lbs.)/each
Rear speaker section
Type:100 mm (4") full-range speaker
Maximum input power:10 W
Impedance:16 ohms
Dimensions:Width; 170 mm (6-11/16")
Height; 120 mm (4-3/4")
Depth; 175 mm (6-7/8")
Weight:0.6 kg (1.3 lbs.)/each
CD-C405
SPECIFICATIONS
CP-C410
CP-SR421
Specifications for this model are subject to change without prior
notice.
VOLTAGE SELECTION (CD-C405W)
Before operating the unit on mains, check the preset voltage. If the votage is different from your local voltage. Slide the AC power
supply socket cover by slightly loosing the screw to the visible indication of the side of your local voltage.
