CD-BA1300H
-“ 8 -“
7
Listening to a tape
1Press the ON/STAND-BY button to turn the power on. 4Press the TAPE (1 2) button to select the TAPE 1
or TAPE 2. 3Load the cassette into the TAPE 1 or TAPE 2 cassette
compartment. 2Open the cassette door by pushing the area marked
"PUSH EJECT". 5 Press the button to start playback. 1Press the ON/STAND-BY button to turn the power on. 2Press the TUNER (BAND) button to select FM ST, FM
or AM. 4Adjust the sound volume using the VOLUME buttons. 6Adjust the sound volume using the VOLUME buttons. 3Press the TUNING/TIME ( or ) button to tune in-
to the desired station.
Listening to the radio
6
1Press the ON/STAND-BY button to turn the power on. 2Press the CD button. 3Press the OPEN/CLOSE button to open the disc tray. 4Place the CD(s) on the disc tray, label side up. 5When loading a third disc, press the DISC SKIP button
to turn the disc tray, then place the CD in the open pos-
ition. 6Press the OPEN/CLOSE button to close the disc tray.
Listening to a CD
5
7Press the button. 8Adjust the sound volume using the VOLUME buttons. And then, close the cassette door completely until it is locked.
1
24
3
TAPE 1
TAPE 2
PUSH
EJECT
PUSH
EJECT
1
5 6
3
2 3 4
2
4
1
2
5
3,6
7 8 5
12 cm (5")
8 cm (3")
Resetting the microcomputer
1Press the ON/STAND-BY button to enter the stand-by
mode. 2Whilst pressing down the button and the
EQUALIZER/X-BASS/DEMO button, hold down the
ON/STAND-BY button for at least 1 second.
"CLEAR AL" will appear.
Caution:
The operation explained above will erase all data stored
in memory including clock and timer settings, and tuner
and CD presets. If this product is subjected to strong external interference
(mechanical shock, excessive static electricity, abnormal
supply voltage due to lightning, etc.) or if it is operated in-
correctly, it may malfunction or the display may not func-
tion correctly. If such a problem occurs, do the following:
CD pickup cleaning
1Press the ON/STAND-BY button to turn the power on. 3Press the CD button and load the desired disc. 2Load a cassette into the TAPE 2 cassette compartment. 4Press the REC PAUSE button. 5Press the button.
Recording from CDs
8 Clean the dust or stain on the CD pickup lens
using a commercial cleaning disc (brush type).
Cleaning disc
TAPE 2
PUSH
EJECT
1
5 4
2 3 1,2
2 2
