Page 1
English 1
PRECAUTION
Location
For safe operation and satisfactory performance of your
unit, keep the following in mind when selecting a place for
its installation:
Shield it from direct sunlight and keep it away from sources
of intense heat.
Avoid dusty or humid places.
Avoid places with insufficient ventilation for proper heat
dissipation. Do not block the ve ntilation holes at the top and
bottom of the unit. Do not place the unit on a carpet
because this will block the ventilation holes.
Install the unit in a horizontal position only.
Avoid locations subject to strong vibrations.
Avoid moving the unit between cold and hot locations.
Do not place the unit directly on top of a monitor TV, as this
may cause playback or recording problems.
Avoiding Electrical Shock and Fire
Do not handle the power cord with wet hands.
Do not pull on the power cord when disconnecting it from
an AC wall outlet. Grasp it by the plug.
If any liquid is spilled on the unit, unplug the power cord
immediately and have the unit inspected at a factory-
authorised service centre.
Do not place anything directly on top of this unit.
SERVICE
This unit is a precision instrum ents and if treated with care,
will provide years of satisfactory performance. However, in
the event of a problem, the owner is advised not to attempt
to make repairs or open the cabinet. Servicing should
always be referred to your dealer or Sanyo Authorized
Service Centre.
For EU Users
Your SANYO product is designed and
manufactured with high quality materials
and components which can be recycled
and reused.
This symbol means that electrical and
electronic equipment, at their end-of-life,
should be disposed of separately from
your household waste.
Please dispose of this equipment at your local community
waste collection/recycling centre.
In the European Union there are separate collection
systems for used electrical and electronic products.
Please help us to conserve the environment we live in!
WARNING:
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR OTHER MOISTURE.
To avoid electrical shock, do not open the cabinet.
Refer servicing to qualified personnel only.
If the power supply cord (AC power cord) of this
appliance is damaged, it must be replaced. Return to a
SANYO Authorised Service Cent re for replacement of the
cord.
CAUTION!
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type
recommended by the manufacturer.
Discard used batteries according to the manufactures
instructions.
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR
YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
Page 2
2 English
INTRODUCTION
Main features
-˛Stores recorded images on CD-R/RW and
DVD+R/+RW.
Accessories
Check that you have all the parts shown below.
Power cord
USB cable
Core clamp (x1)
For USB cable
Fitting (x1)
Screw (x3)
Power cord tie (x3)
Instruction Manual
Copyright
z This manual and software are copyrighted by Sanyo
Electric Co., Ltd.
z Brand and product names used in this manual are the
trademarks or registered trademarks of their respective
companies.
z Except for personal use, copyright law prohibits the use of
recorded copyrighted images without the permission of the
copyright holder.
CONTENTS
1 BEFORE USE ................................................. 3
Notes on installation lo cations......................... 3
Do not put your hand in the disk tray .............. 3
Do not up end the unit ..................................... 3
Handling .......................................................... 3
Important recordings ....................................... 3
Optical media .................................................. 3
Do not use warped or cracked disks ............... 3
Disk handling and storage............................... 3
Cleaning the disk............................................. 4
Precautions for the disk................................... 4
2 NAMES AND FUNCTIONS OF PARTS ......... 5 Front panel ...................................................... 5
Rear panel....................................................... 5
1 INSTALLATION AND CONNECTION TO DVR........................................................... 6
Installation ....................................................... 6
Connection ...................................................... 7
2 FORMATTING DISKS .................................... 8 Formatting CD-RWs and DVD+RWs .............. 8
APPENDIX ......................................................... 10 Specifications ................................................ 10
Dimensions ................................................... 10
INTRODUCTION
OPERATION
OTHER
