Page 1
1
IMPORTANT SAFETY PRECAUTIONS .... 2
FEATURES ............................................. 5
ABOUT DISCS ....................................... 6
BEFORE OPERATION ............................. 8
PREPARATIONS BEFORE OPERATION. 10
Front Panel ..................................................... 10
Rear Panel ...................................................... 11
VFD................................................................. 12
Names and Layout of Remote Controls ......... 13
CONNECTIONS ................................... 14
BASIC OPERATIONS ............................ 15
Play Discs ....................................................... 15
System Setting ................................................ 16
V-Mode .......................................................... 16
Display............................................................ 16
Fast Play ......................................................... 17
Slow Play ........................................................ 17
Pause/ Step ..................................................... 17
Select Audio Language ................................... 18
Select Channels .............................................. 18
Select 3D Audio .............................................. 18
PLAYING A DESIRED SCENE ............... 19
To skip scenes in a disc................................... 19
Directly moving to a desired title (DVD/VCD) . 19
Playing a disc containing MP3 files ................ 20
Repeat Play .................................................... 20
Repeating a defined period from A to B (DVD) .. 21
Select a Subtitle Language ............................. 21
Searching.........................................................22
PLAY DISCS IN VARIOUS WAYS .......... 23
Select Angle.................................................... 23
Zoom Play....................................................... 23
Book Mark ...................................................... 24
Program Play (DVD) ........................................ 25
Program Play (VCD) ........................................ 26
Digest Play (DVD) ............................................27
Digest Play (VCD) ............................................28
Digest Play (CD)...............................................28
Play MP3, JPEG or PICTURE CD ...................... 29
FUNCTION SETTING ........................... 30
Menu Setting .................................................. 30
Language........................................................ 32
Video .............................................................. 33
Audio .............................................................. 34
Preference ...................................................... 36
OTHERS ............................................... 37
Troubleshooting ............................................. 37
Technical Specifications .................................. 38
TABLE OF CONTENTS
DVD-DX405(K501)CA (GB) 2006.6.19 1:24 PM ˘`1
Page 2
2
IMPORTANT SAFETY PRECAUTIONS
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
dangerous voltage within the products
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and servicing
instructions in the literature accompanying the
appliance.
WARNING :TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
CAUTION :TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
IMPORTANT FOR LASER PRODUCTS
- LASER: This Digital Video Disc Player employs a Laser System. To ensure proper use of this
product please read this owners manual carefully and retain for future reference. Should
the unit require maintenance, contact an authorized service location - see service
procedure.
Use of control adjustments or the performance of procedures other than those specified
may result in hazardous radiation exposure.
To prevent direct exposure to the laser beam, do not try to open
the enclosure. Visible laser radiation when open and interlocks
defeated.
DO NOT STARE INTO THE BEAM.
- DANGER: Visible laser radiation when open and interlock failed or
defeated. Avoid direct exposure to beam.
- CAUTION: Do not open the top cover. There are no user serviceable parts inside the Unit; leave all
servicing to qualified service personnel.
CLASS 1
LASER PRODUCT
CAUTION: Any changes or modification in construction of this device which are not
expressly approved by the party responsible for compliance could void the
users authority to operate the equipment.
ATTENTION: KEEPING THE STATUS OF STOP MORE THAN 5 MINUTES ENTERS SCREEN SAVE MODE. WHEN
THE SCREEN SAVE MODE IS KEPT MORE THAN AN HOUR, THE SET ENTERS STAND-BY MODE.
CAUTION: Apparatus shall not be exposed to dripping or splashing and no objects filled
with liquids, such as vases, shall be placed on the apparatus.
