Page 1
- 1 -
SPECIFICATIONS
General
Output power ......................... 12.5 W x 2
(at 4 ohms, 10% distortion)
Inputs ..................................... VIDEO IN : 400 mV / 50k ohms
Outputs .................................. SPEAKERS : 4 ohms
PHONES : 8 - 32 ohms
OPTICAL OUT:Optical
Power requirements ............... AC 230V, 50Hz
Power consumption ............... 40 W
Dimensions (W x H x D) ........ Approx. 160 x 251 x 207 mm
Weight .................................... Approx. 3.2 kg
Speaker system
Type ....................................... 3 way bass reflex
Unit used : Woofer ................. 10 cm cone type
: Mid range ............. 5 cm cone type
: Tweeter ................ 2 cm piezoelectric
Maximum
power-handling capacity ..... 25 Watts (peak)
Nominal impedance ............... 4 ohms
Dimensions (W x H x D) ........ Approx. 150 x 245 x 224 mm
Weight .................................... Approx. 1.9 kg (per speaker)
Specifications subject to change without notice. Tuner
Reception frequency .............. FM : 87.5 - 108.0 MHz
MW: 522 - 1611kHz
LW : 144 - 288kHz
CD player
Channels ................................ 2-channel stereo
Sampling frequency ............... 44.1 kHz
Pick-up ................................... Optical 3-beam
semiconductor laser
Wow and Flutter ..................... Below measurable limits
Wave length ........................... 790 nm
Laser output ........................... 0.6mW(Continuous wave max.)
Cassette deck section
Track system ......................... 4-track, 2-channel stereo
Frequency response .............. 60 Hz - 13.5 kHz
Signal to noise ratio ............... 50 dB
Wow and Flutter ..................... 0.12% (WRMS)
Fast forward / Rewind time .... Approx. 110 sec. (C-60)
SYSTEM CONNECTIONS
Video/Auxiliary equipment External aerial
AM loop aerial
Aerial wire
Digital equipment
R ch speaker L ch speaker
Amplified Subwoofer
To an AC outlet
Page 2
- 2 -
LASER BEAM SAFETY PRECAUTION
- Pick-up that emits a laser beam is used in this CD player section.
CAUTION :
USE OF CONTROLS OR ADJUSTMENTS
OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE
LASER OUTPUT .......... 0.6 mW Max. (CW)
WAVELENGTH ............. 790 nm
CAUTION -“ INVISIBLE LASER RADIATION WHEN OPEN AND
INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM.
ADVARSEL -“ USYNLIG LASER STRĂ…LING VED Ă…BNING, NĂ…R
SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION, UNDGÅ UDS ÆTTELSE
FOR STRĂ…LING.
VARNING -“ OSYNLIG LASER STRĂ…LNING NĂ„R DENNA DEL Ă„R Ă–PPNAD
OCH SPĂ„RR Ă„R URKOPPLAD. STRĂ…LEN Ă„R FARLIG.
VORSICHT -“ UNSICHTBARE LASERSTRAHLUNG TRITT AUS, WENN
DECKEL GEĂ–FFNET UND WENN SICHERHEITSVERRIEGELUNG
ĂśBERBRĂśCKT IST. NICHT, DEM STRAHL AUSSETZEN.
VARO -“ AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET ALTTIINA
NĂ„KYMĂ„TTĂ–MĂ„LLE LASERSĂ„TEILYLLE. Ă„LĂ„ KATSO SĂ„TEESEEN.
CD PICK-UP MAINTENANCE
About pick-up (Optical lens) Cleaning
Clean a lens with swab of the cotton which moistened it with alcohol, cleaning paper or cleaning disc appointed.
Specified cleaning disc : LC-1 (Part code : 645 026 1961 ..... manufactured by SANYO.)
Show a clean procedure in the following in reference by swab of cotton.
1. Cotton swab is wrapped with Cleaning paper.
2. Add the isopropyl alcohol.
3. Gently move the tip of cotton swab just like a draw a whirlpool from inside to outside on the surface of lens.
CD PLAYER ADJUSTMENTS
1. ADJUSTMENTS
(1) Confirm the tracking balance
1. Turn on the POWER switch.
2. Connect an Oscilloscope to TP2 (TE) and TP4 (VC).
3. Set the test disc.
4. Press "PLAY" button to turn into the "PLAY" mode.
5. Keep holding "SKIP" button down so as to be "SERCH"
mode, then confirm that the oscilloscope waveform is
symmetrical on the top and bottom in relation to 0V (VC).
200mV/div.
5ms/div.
