Sansui TV19 PL120DVDA Owners Manual

Page 1

Note: - When installing the set on a wall, allow at least 10 cmclearance between the rear of the set and the wall. Clearance of less than 10 cmwill obstruct the vents and cause the interior of the set to overheat, resulting in faultsor damage to the set. - If the unit is mounted on the wall, contact the shop where you purchased the unit for advice, and leave the installation work to experts. Incomplete installation work can cause you injuries. - The apparatus must be connected to a mains socket outlet with a protective earthing connection. - The socket outlet must be installed near the equipment and easily accessible. * The HD ready Logo is a trademark of EICTA. Safety warnings Plasma and LCD TV Screen Burn Warning A characteristic of Plasma and LCD TV Panels is that displaying the same image for a long time may cause a permanent after-image to remain on the screen. This is called screen burn. Most pictures shown on your TV will be constantly moving and fill the screen. Examples of images that you need to watch out for are as follows (this is not an all-inclusive list): -Black Bars: If black bars appear at the left/right or top/bottom of the screen it is recommended to change the format so that the picture fills the entire screen. -TV Channel Logos: e.g. Shopping channel logos and pricing displays - especially if they are bright and stationary. Moving or low-contrast graphics are less likely to cause ageing of the screen. -PIP and Multipip: Do not view for long periods of time using the PIP or Multipip functions. -Time Displays -Teletext: Do not view a stationary page for long periods of time. -TV/DVD Menus: e.g. Listings of DVD disk content. -Pause Mode: Do not leave the screen in pause mode for long periods of time, e.g. When watching DVDs or videos. Note: To prevent screen burn if viewing any of the above for long periods of time, reduce contrast and brightness when viewing. Once burn-in occurs it will never disappear completely. Batteries Batteries are easily swallowed by young children. Do not allow young children to play with the remote control unit. Covers - Do not remove any fixed covers as this may expose danger- ous voltages. Standby Do not leave your TV in standby for long periods of time e.g. overnight or while on holiday. We recommend that you switch off / unplug at the mains power supply. CAUTION: THIS UNIT IS A CLASS 1 LASER PROD- UCT. HOWEVER THIS UNIT USES A VISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EX- POSURE IF DIRECTED. BE SURE TO OPERATE THE PLAYER CORRECTLY AS INSTRUCTED. WHEN THIS UNIT IS PLUGGED INTO THE WALL OUTLET, DO NOT PLACE YOUR EYES CLOSE TO THE OPEN- INGS TO LOOK INTO THE INSIDE OF THIS UNIT. USE OF CONTROLS OR ADJUST- MENTS OR PERFORMANCE OF PRO- CEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPO- SURE. DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERV- ICING TO QUALIFIED PERSONNEL. Damage - Never use your TV if it is damaged in any way. Always place your TV on a flat level surface avoiding anywhere which may be subject to strong vibration. Weather - It is advisable to unplug the aerial during an electrical storm. Moisture - Do not allow your TV to be exposed to rain, moisture or dust. If any liquid is spilt into your TV it can cause serious damage. If you spill any liquid into your TV switch it off at the mains immediately. Con- tact your store. Interference Do not place your TV on or near appliances which may cause electromagnetic interference (TV or Hi-Fi speakers). If you do, it may adversely affect the working of the unit, causing erratic playback, distorted picture or sound.Attention! Cleaning instructions for your LCD TV. Safety note: Before you start to clean, switch the set's power off completely and disconnect the plug from the mains power supply. Be careful not to scratch the plastic coated front panel - it is highly vulnerable to accidental scratching (e.g. by fingernails or other sharp items). While cleaning, do not wear jewellery that could cause surface scratching (such as rings, wrist- watch, etc.). Use a lint-free cloth and pure water to clean with, but make sure the cloth is thoroughly wrung out so that it is just damp and not soaking wet - also make sure that the cloth is free from any dirt that could cause scratching to the surface. Wipe the set clean using minimal pressure. Do not use standard window cleaning fluid. Its alcohol / ammonia will dissolve the front window's coating. Never use solvent or thinner. Never use special cleaners which are designed for cleaning PC Monitors or CRT TVs. Finally carefully rub dry with a clean dry lint-free cloth. Do not use paper towels or tissues to clean the set - paper can disintegrate when wet or may leave a trail of dust behind. Some paper can also be abrasive and scratch your screen. Temperature Avoid extremes of temperature, either hot or cold, place your TV well away from heat sources such as radiators or gas/electric fires. Ventilation The TV must be well ventilated. Do not cover your TV or place inside a small confined space. It is recom- mended that you leave a 10cm gap all around your TV.

Page 2

1 Contents-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹ Location of controls ......................................... Page 2 Aerial connection ........................................... Page 3 Connection to other equipment ..................... Pages 4-6 PC Connection ........................................... Pages 7-8 Connecting an HDMI or a DVI device to the HDMI input .................................................... Page 9 Analogue Menu System ................................. Page 10 On-screen Language Selection ........................ Page 10 Auto setup ................................................... Page 11 Auto tuning .................................................. Page 12 Changing the order of stored channels ............ Page 12 Manual tuning .............................................. Page 13 Basic TV functions ......................................... Page 14 Teletext ........................................................ Page 15 Adjusting the NICAM stereo sound ................. Page 16 Picture format ............................................... Page 17 Other useful functions .................................... Page 18 Guide to using the Digital Menu System .......... Page 19 Language Setup ............................................ Page 20 Auto Scan .................................................... Page 20 Manual Scan ............................................... Page 21 Carrier Setup ............................................... Page 21 Channel Organizer ................................. Pages 22-23 Display Setup ............................................... Page 24 Password Setup (Parental lock) ....................... Page 24 Version ........................................................ Page 25 Software Upgrade ........................................ Page 25 Common Interface ........................................ Page 25 Moving the unit or carrying by hand When the unit is moved a long way, unplug the power cord and disconnect the aerial, connecting leads and any fall-prevention apparatus. - Moving without doing so could result in damage to the power cord, a fire, electric shocks or injuries from dropping the unit. The distance between eyes and the screen should be about 5 ~ 7 times as long as diagonal length of the screen. - Viewing from too close a distance can cause strain for your eyes. When installing the Monitor on a table, be careful not to place the edge of its stand. - This may cause the Monitor to fall, causing serious injury to a child or adult, and serious damage to the Monitor. Channel list .................................................. Page 26 Channel banner ........................................... Page 27 Multi audio .................................................. Page 28 DVB-Subtitle ................................................. Page 28 DVB Text ...................................................... Page 29 EPG (Electronic Program Guide) ..................... Page 30 EPG Timer .................................................... Page 31 Disc ............................................................ Page 32 Playing a disc ........................................ Pages 33-35 Zooming ...................................................... Page 36 Locating Desired Scene ................................. Page 36 Marking desired scenes ................................. Page 37 Repeat Playback ........................................... Page 38 A-B Repeat Playback ..................................... Page 38 Changing Angles .......................................... Page 39 Title Selection ............................................... Page 39 DVD Menu ................................................... Page 39 Changing Soundtrack Language ..................... Page 40 Subtitles ....................................................... Page 40 Disc Status ................................................... Page 40 MP3/WMA/JPEG and Audio CD operation ............................................... Pages 41-45 Program playback ........................................ Page 46 Random playback ......................................... Page 46 Customizing The Function Settings ............ Pages 47-50 Temporary Cancel The Rating Level By DVD Disc ................................................ Page 51 Language Code List ....................................... Page 52 Before Requesting Service ........................ Pages 53-54 Specifications ............................................... Page 55

Page 32

31 -—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹\ -—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹\ -—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹ -—‹-—‹ EPG Timer 1 Press GUIDE to display the Guide menu. Then press C/D /B /A to highlight the programme you want to set as an event timer, then press ENTER. Note: - If you select an event which has already started, the selected program will be displayed on the screen, as you cannot set the timer for a programme whi\ ch has already started. - To display the stored event timer, press GUIDE twice. The EPG Timer menu (see step 3 below) will appear. You can also delete or change the frequency (Once / Daily / Weekly) of the stored event timer (but please note that you cannot edit the time details that have been set from the EPG). 2 The confirmation banner will be displayed. Press B or A to select Yes or No, then press ENTER (the selected option is shown in blue). 3 The EPG Timer menu will appear. Press the Red key to set the Timer mode for a selected event. 4 The Timer mode specifies the frequency of Timer wake-up which can be set as Once, Daily or Weekly. Press ENTER to save the selected Timer mode. Note: To delete an event timer, select the specified event, then press the Green key. 5 To return to the Guide menu, press DIGITAL MENU. To clear the menu screen, press EXIT. Note: - Press the Yellow key to change the start time of the event. - Press the Blue key to change the time duration of the event. - If the unit goes to standby mode (by pressing (STANDBY ) on the unit or (STANDBY ) on the remote control) after the EPG Timer has been set. You can choose whether or not the screen switches on when the event timer begins - please see page 18 (Rec screen status (LCD Power on/ off)). This is so that if you are using the timer to make a re- cording to your VCR or other device, the TV screen will not switch on unless you want it to. If you try to switch to another channel while an event timer is in progress, the following message will appear:WARNING: CHANG- ING THE CHANNEL WILL INTERRUPT YOUR EVENT TIMER. ARE YOU SURE YOU WANT TOPROCEED? YES/NO. Select YES or NO according to your wishes. Note: - A maximum of eight Timers can be programmed. - If the EPG Timer starts when it is already switched on, it will start at the exact time that is set. If it starts from the standby mode, it will begin 20 seconds in advance of the stated time. - You cannot hasten the start time from the original start time of the Event. - You cannot set with the same date and time of another Event. - The programme set as event timer will be highlighted in the Guide menu. Guide 16:50 Sun 20 08/2007 TV Page Page + Prev Day Next Day BBC ONE BBC TWO TV1 Channel4 Five The W ld Thornberrys Bogged Down: Nigel and E iza are on the r way to f lm a rare f sh Nigel suggests a shortout through a bog, but Ellza is re uctant Th 16:30 17:00 The W ld Thornberrys CBBC 001 BBC ONE Sun 20/08/2007 16:30 Channels The Wild T Ready Steady Co Little Be No Event Name No Event Name No Event Na 17:30 17:00 The Blue The Weakest Link No Event Name Enter Exit View Info TV Radio Navigate Confirmation This programme has not yet started Do you want to set a timer event ? Ye s No Event Timer Navigate Enter Ex t Serv ce Name Mode Date Time Duration BBC ONE Once 26/02 02 8:10 00:23 Timer mode Delete Timer Edit Timer Edit Duration Event Timer Service Name Mode Date BBC ONE Once 26/02/02 Once Daily Weekly

Page 56

55 -—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹-—‹ -—‹-—‹ Specifications TELEVISION System: Analogue: PAL UK, IR, CCIR, FRENCH System, B/G, D/K, I/I, L Digital: DVB-T (OFDM 2k/8k 16QAM/64QAM) AV Input receivable: NTSC 3.58, NTSC 4.43/PAL 60 Preset channels: Analogue channels (99) + Digital channels (Carrier 200/Service1000) Frequency Range: Analogue: IreE2~E4, X~Z+2, S1~S10, E5~E12, S11~S41, E21~E69 Digital: E5~E12, ItaE~G, F1~F6, Rus6~12, E21~E69 LCD: 18.95 TYPE (48.14 cm visible) TFT low-glass Active Matrix Colour LCD, 1440 x 900 Pixel Viewing Angle:Left/Right: 80 degree, Up/Down: 80 degree Terminals Antenna input: UHF/VHF 75 Din type (Analogue Digital) AV1: SCART (AV input, RGB input, TV output) AV2: S-VIDEO (Y/C input), RCA pin (AV input) COMPONENT: COMPONENT (Y/PB (CB)/PR (CR) input), RCA (Audio input) HDMI: HDMI, Ø 3.5 mm jack (Audio input*) PC: Ø 3.5 mm jack (Audio input*), 15 pin mini D-sub (PC/ Component) C. I. (Common Interface): EN50221 DIGITAL AUDIO OUTPUT: RCA pin (Audio) Headphones: Ø 3.5 mm jack (Audio output) * Audio input that share with HDMI and PC. Audio Output Power: 1.5W x 2 (MAX) DVD Signal system: Applicable disc: Frequency response: S/N Ratio: Harmonic distortion: Output: Pickup: GENERAL Power Source: Power Consumption: Weight: Dimensions: Operating Temperature: REMOTE CONTROL UNIT Power Supply:NTSC, PAL DVD (12cm, 8cm), CD (12cm, 8cm) DVD: 4Hz - 22KHz, CD: 4Hz - 20KHz 85dB 0.02% Audio : (RCA) -“12.0 dBm, 1 k Digital Audio : 0.5Vp-p/75 CD : Wavelength: 775 - 805 nm Maximum output power: 0.5 mW DVD : Wavelength: 640 - 660 nm Maximum output power: 1.0 mW AC 220-240V, 50Hz 60 W 6.7 kg 483(W)x396(H)x190(D)mm 5°C to 40°C DC 3V (Two batteries, AA/ R6/ UM-3) Weight and Dimensions are approximate. Because we continually strive to improve our products we may change specifications and designs without prior notice.
