Page 1
2
Safety instructions
This user manual contains important safety instructions and information for proper use of
the device. Please follow the instructions in this manual carefully.
APlease keep the device away from places with high temperatures, high humidity or dust.
BDo not give your car radio and especially the accessories to children.
C Avoid shocks and do not let the device fall, as that may cause damage to the device.
DWe are not responsible for data losses that are caused by damage to the product, repairs
or any other reasons.
E Do not disassemble the device. Doing so will void your warranty claims.
FDo not use alcohol, thinners or petrol to clean the display. Use only a dry cloth.
Accessories
Package contains the following accessories for installation and operation the unit.
Washer, spring
Washer, M5 Nut 1
Rubber
cushion1
WEEE (Waste Electrical and Electronic Equipment Directive)
Waste electrical products should not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local Authority or retailer for recycling advice.
Copyright Information
©2009 All rights reserved. This document may not in whole or in part be reproduced, stored in a retrieval
system, transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or
otherwise, or reduced to any electronic medium or machine-readable form without prior consent, in
writing, from [COMPANY].
[PRODUCT] and [BRAND] are registered trademarks of [COMPANY]. The logos, standards, software,
and/or product names mentioned herein are manufacturer and publisher trademarks and are used only
for the purpose of identification.
Disclaimer
The publishers and author assume no responsibility whatsoever for the uses made of this material or for
decisions based on its use. Further, [COMPANY] makes no warranties, either expressed or implied,
regarding the contents of this product, its completeness, accuracy, merchantability, or fitness for any
particular purpose. Neither the publisher nor anyone else who has been involved with the creating,
production, or delivery of the material shall be liable for any reason.
All brand and product names used throughout this document are trademarks or registered trademarks of
their respective companies. The brand and product names are used in editorial fashion only and for the
benefit of such companies.
Product specifications are subject to change without prior notice
www.sansui-caraudio.com
Page 2
3
Mounting Strap 1 Screw 4
Bolt 1
key 2
Screw 1
sleeve 1
ISO Cable 2
Manual 1
Installation in Dashboard
If your car is fitted with a one (1x) DIN size opening for a car audio system, you can install the Car Radio
according these steps.
Note: Unit should be installed horizontally in an angle less than 30°.
1) Insert the mounting bracket into the 1X DIN opening of your dashboard.
2) Bend the mounting tabs outwards with a screwdriver, to tighten and fix the mounting bracket in its place.
3) Connect the M5 Bolt to the rear of the unit.
4) Check electrical connections as described earlier (either an ISO connection or separate wiring)
5) Insert the ISO connector into the unit.
6) Push the unit into the mounting bracket until you hear a click
7) Move the assemble bar (metal strip with holes) over the M5 bolt. And use the M5 nut to tighten the
assemble bar.
8) Use the screw Bt5x20 to fix the other side of the assemble bar to the car body.
9) Place the front rim over the unit to finish the installation.
Wiring Connections
Note: Never connect cable to the system while it is connected to the battery power. Whenever the unit is
disconnected from the battery, the preset memory will be erased and the unit will go back to its factory
defaults.
1X DIN SLOT
