Sansui R 707 R 707L Service Manual

Page 13

5-3. Top View

Parts List

Parts List

R-707/707L

Pans No. Stuck No. Dascription Parts No. Stock No. Description
1 07978200 Front Panel ASS'Y (RA707) 1 33004700 Power Supply Cord (R-707)
07975300 Front Panel Ass'y (R-707Ll 38004500 Power Supply Cord (R»707Ll
2 07952400 Bonnet 2 15009201 Power Transformer (Fl-707)
3 07932400 Knob, BASS, TREBLE, BALANCE 15009205 Power Transformer (R707 L)
46363100 50kfl X 2 250kfl VR, BASS, TREBLE, 3 46364100 8P Push Terminal, speaker
BALANCE 4 22301500 Ground Terminal
4 07924000 Knob, AUTO 5 46364200 Antenna Terminal
46395900 Push SW., AUTO 6 46363700 2P Terminal, PHONO
5 07925000 Knob, TAPE-1 7 46148200 Jack , COMPU SELECTOR
46395900 Push SW., TAPE-1 8 46371500 4P Tarminal, TAPE71 , TAPE-2
6 47012000 Display Cover (Fl-707) 9 07952700 Side Panel-Fl
47012100 Display Cover (Fl-707L) 10 07934100 Joint Shaft (C).
7 07953900 Display Panel 11 07934000 Joint Shaft (B),
3 47011700 Display Holder 12 07952600 Side PaneIAL
9 47025800 Cushion Rubber 13 07917700 AC Cord Cover
10 07924400 Knob, PHONO 46399400 AC OUTLETS (Fl-707)
46395900 Push SW., PHONO 46161000 AC OUTLETS (R-707L)
1 1 07924300 Knob, FM 07204700 Slide SW1, VOLTAGE SELECTOR
46$5900 Push SW., FM iR-707L)
12 07932600 Knob, VOLUME
46395300 1501} Slide VFl, VOLUME
13 07924200 Knob,AN
46395900 Push SW,, AM
14 07917200 Knob, LOUDNESS
46360900 Push SW,, LOUDNESS
15 07931500 Knob, FM MUTING/MODE,TAPE-2
46351000 Push SW1, FM MUTING/MODE,
TAPE-2
16 47021100 Knob,MEMORY
46395900 Push SW., MEMO RV
17 07931100 Knob, FM/AM PRESET
46395900 Push SW., FM/AM PRESET
18 07911300 Knob,TUNING
46396700 Push SW1, TUNING
19 07924100 Knob, MANUAL
46395900 Push SW1, MANUAL
20 47005500 Knob, SPEAKERS
46361100 FUSh SW1, SPEAKERS
21 46265700 Jack. PHONES
22 07971210 Knob, POWER
Push SW., POWER

46364300

12
