INli'ilISH

STEREO INTEGRATED AMPLIFIER RA-82OBX2

INTRODUCTION

We at Rotel want to thank you for purchasing our audio
product.

Flotel audio products are designed to use the latest electronlc
technology, and they Incorporate our long experience as a
speclalist manufacturer of audio equment. We are confident
that you Will find satisfaction in the high quality sound and
top performance, and that you will find pleasure in the
functional beauty achieved through humanrengineering
concept. Before starting operation, please read this
instruction manual thoroughly and acquaint yourself With the
proper mode of using the unit and all ist connections

We hope you Will enioy toprnotch performance for many
years to Come

BEFORE ENJOYMENT/POWER SUPPLV

Follow the Instructions below for maximum safety:

1. Use a wall outlet for power supply

Be sure to connect the AC llne cord to a household wall
outlet Be certain that the outlet voltage matches the
electrical rating of the unit, found on the rear panel name
plate

2. Connecting and removing AC card

Be sure to connect or disconnect the AC line cord only
after turning off the power sWitch to prevent possrble shock
noise or damage to the speakers.

3. Veritilate the unit well

Never block any ventilation holes at the top and bottom of
'the unit, Be sure also to provide ample ventilation space
around the unit. Poor ventilation may result in damage due
to excessive heat

4. Do not open the cabinet

In order to av0id electric shock or damage to the component,
never open the cabinet If a foreign obiect falls inside the unit
by mistake, turn the power off, disconnect the wall plug. and
consult a qualified electrician or your dealer

5. Installation

Be sure to place the unit in a level and flat place where it
is free from humidity, Vibration, high temperature and not
exposed to direct sunlight. Be careful not to place the unit
in a highly enclosed place such as near a wall or on a
bookshelf, A poor ventilation Will cause undesirable effects
to the unit.

6. Moving the unit

When transporting, remove the AC cord from the wall
outlet and all other connected cards on the rear panel to
prevent Wire breakage and short circuits.

7. If the unit gets wet

If you unit should get wet. immediately disconnect the AC
cord, and consult your dealer or a qualified electrician.

8. Cleaning and maintenance

Do not use chemicals such as benzine or thinners on the front
panel. Always use a soft, dry cloth to clean the unit.

9. Owner's manual

Keep the owners manual near the unit, and record the
serial number (found on the rear panel) on the cover.

SPEAKERS

Use speaker systems With impedance ratings of 4716 ohms.
Before hooking up your speaker system, be sure to check
its impedance, which should be indicated either on the back
of the speaker, or in the speaker instruction manual.

HOOKING UP SPEAKERS

VourRotelamplifier prowdes the IaClllIV for either direct or
switched speaker Connection

The direct sockets in keeping With our design philosophy,
incorporate 'straighi line signal paths. When usrng
headphones lor private listening it Will be necessary to
disconnect your loudspeaker leads from the amplifier
connection instructions are shown in diagram A'.

The sWitched sockets Will prowde the convenience of
sWitching off the speakers when using headphones for
private listening, Connection instructions are shown in
diagram '3'

The speaker terminals are combined binding posts and 4mm
sockets suitable for use With 4mm banana plugs or direct
attachment of speaker Wires.

SPEAKER (RIGHT) SPEAKER (LEFT)

66¢ ,

oinct COMMON swncHED.

26: ?6 ER L I

7A-

9 i
i

,3,

EXCLUSIVE NOTE FOR U.K.

If your unit comes With a 3-core cable Without a
plug, make certain live, neutral and earth leads are
connected to the proper terminals. Check that the
terminals are screwed down firmly and no loose
strands of wire are present.

IMPORTANT: The wires in this mains lead are coloured
in accordance with the following code:
GREEN/YELLOW: EARTH

BLUE : NEUTRAL

BROWN : LIVE

As the colours of the wires in the mains lead of this
apparatus may not correspond with the coloured
markings identifying the terminals in your plug
proceed as follows. The Wire which is coloured
GREEN/YELLOW must be connected to the terminal
in the plug which is marked by the letter E or by
the safety earth symbongm or coloured GREEN or
GREEN/YELLOW. The wire which is coloured BLUE
must be connected to the terminal which is marked
With the letter N or coloured BLACK. The wire Which
is coloured BROWN must be connected to the terminal
which is marked with the letter L or coloured RED.
