Continuous Power Output 60Watts/ch (20-20kHz, < 0.03%, 8Ω)
Total Harmonic Distortion (20Hz-20kHz)
< 0.03% at rated power
Intermodulation Distortion (60 Hz:7 kHz, 4:1) < 0.03% at rated power
Frequency Response
Phono input 20Hz-15kHz, ±0.3dB
Line Level Inputs 10Hz-100kHz, ±1dB
Input Sensitivity / Impedance
Phono input 2.5mV / 47 k Ω
Line Level Inputs 150mV / 24 k Ω
Input Overload
Phono input 180mV
Line Level Inputs 5V
Preamp Output / Impedance
1V / 470Ω
Tone Controls - Bass / Treble
±4 dB at 100Hz / 10kHz
Signal to Noise Ratio
(IHF A weighted)
Phono input 80dB
Line Level Inputs 100dB
DIGITAL SECTION
Frequency Response
10Hz-95kHz ±3.0dB (MAX)
Signal to Noise Ratio
(IHF A weighted)
100dBInput Sensitivity/Impedance
0 dBfs/75V
Pre-out/Impedance 1.2V/470V (at -20dB)
Decodable Front USB/iPod Digital
Signals
AAC (m4a), WAV, MP3, WMA (up to 48K
16bit)
Coaxial/Optical PCM
LPCM
File Formats Real Audio, MP3, OGG Vorbis, WAV, AIFF
and AU
GENERAL
Power Requirements (AC) 120V, 60Hz
(USA) 230V
50Hz (Europe)
Power Consumption
300Watts
Standby Power
Consumption 0.5W
0.5Watts
Dimensions (W x H x D)
430 x 92 x 342mm
17 x 3 5/8 x 13 1/2 in
Panel Height 80mm (3 1/16 ins)
Weight (Net) 8.02kg (18lbs)
Finishes
Black
Silver
RA-12
Specifications
