Page 1
TABLE OF CONTENTS
Rotel Amplifiers, Designed for the Real WorldThe Power SupplyPower AmplifiersSurround Sound ProcessorsDVD PlayersSurround Sound A/V ReceiversStereo Power AmplifiersStereo Pre-AmplifiersTuner, CD Player, Stereo Integrated Amplifiers02 SeriesBack Panels 4
5
6-9
10-11
12-13
14-17
18-19
20-21
22-23
24-29
30-31
EXCEPTIONAL SOUND. NO EXCEPTIONS.
The products you are about to discover in these pages -“ DVD
and CD players, preamplifiers, surround sound processors,
power amplifiers, receivers and more -“ are unique.
They come from a high performance home theatre and high
fidelity components.
We use the word manufacture advisedly. We make everything
from core components to complete products ourselves. In our
own factories. Under our own control.
Is this important?
Extremely.
Among other things, this integration gives us the opportunity
to select everything that goes into a Rotel product. Even down
to what we call board level parts -“ the semiconductors and
passive circuit elements that distinguish merely competent
designs from extraordinary ones. This is an essential part of
our Balanced Design Concept.
Balanced Design Concept is a disciplined synthesis of physics,
electronics and mechanical engineering, guided by our firm
belief that the best need not be the most costly.
Balanced Design begins with basic circuits conceived by an
international team of award-winning engineers. It includes an
exhaustive evaluation of every part used in these circuits to
determine not just which one will do... but which one will do best.
Balanced Design also means that we verify every choice we
make with the most critical and sensitive laboratory instrument
available anywhere --- the human ear.
Thats why our team of trained critical listeners evaluate every
prototype, and then collaborate in fine-tuning basic designs until
they fully meet Rotels demanding standards.
Balanced Design combines both hard science and experienced
intuition to bring you closer to the source-¦any source, be it
music or movies-¦and to let you hear without compromise
exactly what the artists intended you to hear.
Nothing more. And certainly nothing less.
Page 2
5
Of all audio components, the amplifier has
arguably the toughest job. It must provide
a common interface for a diverse range of
source products, including CD, DVD-A, SACD
players and MM/MC phono cartridges. On
the other side of the divide, the amplifier is
also forced to wrestle with the unpredictable
demands of a loudspeaker. In some instanc-
es, the two roles are seemingly incompat-
ible, as the amplifier caresses millivolt
source signals while delivering many tens
of volts and, potentially, as many amperes
of current to maintain a rock solid power
output.
The success of this balancing act depends
largely on power supply design and circuit
layout, especially the ground plane. It is our
custom-built transformers, multiple supply
regulators and symmetrical topologies of all
Rotel amplifiers that provide the foundation
of a performance thats realised in our high-
current, complementary power amp stages.
Our published specifications are very con-ser-
vative, and reflect a maximum continuous
power output that the amplifier will comfor-
tably maintain. In reality, of course, loud- spe-
akers do not behave like the 8 ohm or 4
ohm test loads used for measurement. They
comprise reactive (capacitive and inductive)
elements that force the voltage and current
to become out of step as the impedance
swings as high as 50 ohms or more before
plunging to 2 ohms, or even less, at differ-
ent frequencies.
This ability to grapple with almost any
speaker load, no matter how difficult, sets
Rotel amplifiers apart from the mainstream.Furthermore, real music is quite unlike the
steady state tones typically used for mea-
surement purposes. Music is dynamic, a
mix of chords, crescendos and instrumental
transients that may peak for just a few mil-
liseconds. Once again, Rotel amplifiers are
designed to accommodate these peaks,
delivering huge increases in clean power well
beyond their rated specification.
Take the RB-1050 as an example. Modestly
rated at 70W/8 ohm, it will actually deliver
125W under dynamic, music-like conditions,
increasing to 225W, 375W and 470W into
tougher 4, 2 and 1 ohm loads. This is an
exceptional performance for a mere 70W
amplifier and helps explain why our amplifi-
ers typically sound louder and more dynamic
than competing products with a notionally
similar specification.
But high dynamic power, and therefore high
dynamic current, is of little benefit without
great linearity. Many manufacturers claim
bold figures for peak or instantaneous cur-
rent without specifying the duration of the
peak or how distorted the signal. After all, an
amplifier that can deliver 20A of current at
<1% distortion cannot fairly be compared to
another that suffers 10% or more at the
same output. Our RB-1050 will deliver
470W/1ohm with 10msec peaks at less
than 1% distortion, thats nearly 22A of clean
current from our least powerful model!
Rotel amplifiers: high value audio engineer-
ing designed to tackle the real world, not just
the lab bench.
You will no doubt notice that we spend a lot of time in this brochure describ-
ing Rotels approach to power supply design. Heres why.
A power supply is the heart of any home entertainment component. It pumps,
if you will, proper amounts of current at just the right voltage so that all the
active circuits in your amplifier, DVD player, surround sound processor, etc.,
can do the job they were designed to do.
Power supplies arent black magic. Theyre comparatively simple to design, but
good ones, however, are costly. Thats why few manufacturers describe theirs
-“ an accurate picture might be more embarrassing than enlightening. At
Rotel, we take the opposite approach. We talk about our power supplies
because weve already done our homework and built the manufacturing
infrastructure we need. For example, we design and manufacture our own
transformers in-house. Why? Because a transformer, that critical transition
between AC power from the mains and the rest of your component, must have
enough current capability to satisfy your components active circuitry. And it
must accurately step down the mains voltage to levels that are useable by
subsequent circuit stages.
Making our own transformers gives us a three-fold advantage over the com-
petition. First, we
dont need to shop for a good enough product made
by someone else. Second, we can schedule production so that the right
transformer is available just as the component it was designed for is ready to
receive it. Lastly, we dont have to factor in some other companys profit mar-
gin when we price our products. Given that the transformer is often the single
most expensive part of a component, thats an enormous advantage. For one
thing, it means we can use higher quality capacitors -“ BHC Slit Foils, Aerovox
T-Networks, for example -“ to store and provide the instantaneous current deli-
very that improves a Rotel components ability to deliver the full dynamics of
even the most demanding music selection or soundtrack.
Rotel products simply reproduce sound with greater fidelity to what we know is
real.
Of course, there are other parts to a power supply -“ rectifiers and voltage
regulators, to name but two. These are chosen and configured with the
same meticulous care we lavish on any other part of a Rotel component. So
the next time someone doesnt describe a power supply properly, you can ask
yourself What are they hiding? Or, you can simply buy a Rotel.
ROTEL AMPLIFIERS
THE POWER SUPPLY
DESIGNED FOR THE REAL WORLD
Page 11
Tuner, High Resolution CD Player, Stereo Integrated Amplifiers
23
RA-1062
Hi Fi Choice, August 2003
If they dont know it yet, then
Rotels RA-1062 is an amp that
its peers will grow to hate. It is
solidly and reliably constructed,
offers a generous assortment of
features and delivers a powerful,
purposeful and crisp sound that
pushes all the emotive buttons. All
this and more, but at a price that
represents a slap in the face to its
competition.
The RT-1080 AM/FM tuner is the perfect RF sour-
ce for a custom-installed system, thanks to a bi-
directional RS-232 computer-style interface, dual
antenna inputs, and total remote control capability.
Sound quality comes from the same attention to
detail that distinguishes every Rotel: custom-
wound transformers, high grade power supply
parts, refined audio circuits carefully designed to
reveal all the subtleties FM broadcasts can bring.
The RT-1080 also includes RDS (Radio Data
System) enhancements to make FM broadcast-
ing even more enjoyable.* RDS lets you see your
favorite stations call letters, for example, and the
type of program material theyre broadcasting.
Thirty (30) direct access presets allow you to pro-
gram your favorite stations for quick recall. A vari-
ety of tuning modes and built-in compensation for
US and European FM broadcast standards make
this tuner truly universal.
* RDS functions determined by your local radio stations.
The RCD-1072 proves conclusively that cost-con- scious high performance in a single disc CD player
is still available -“ and still outperforming many so-
called audiophile DVD players.
Utilising circuit configurations originally developed
for Rotels reference class components, this afford-
able unit redefines your sonic expectations. The
segmented power supply features a large toroidal
transformer for minimal power supply sag as well
as reduced hum emissions. High quality rectifiers,
tight tolerance voltage regulation and low-ESR
storage capacitors make sure that all circuits
always operate as their designers intended. The
critical analogue stage uses meticulously selected
parts in a minimalist circuit environment to ensu-
re the finest sound quality.
The RCD-1072 uses the same over-scan disc
mechanism once reserved only for premium priced
players. The remarkable new Burr-Brown PCM-
1732 IC provides advanced digital filtration, HDCD
decoding, and precise D/A conversion. A coaxial
digital output supplements the high current analo-
gue outputs. A high-density FL display, complete
programming capability, remote control, and a 12
volt trigger complete the picture.
The RA-1062 is the evolution of Rotels highlyregarded RA-1060. The design team spent hun-
dreds of hours evaluating individual component
performance from input to output. Chief among
these improvements is the UK designed and manu-
factured T-Network power supply capacitor. These
premium grade components follow the tradition of
our Slit Foil capacitors by incorporating tiny perfora-
tions in the capacitor foil to reduce distortion.
Even more significantly, the T-Network capacitor
has multiple connections that effectively create
several smaller capacitors within a single larger
body and thus ensure far lower voltage intermodu-
lation between input and output.
The result is a striking portrayal of musical subtle-
ties supported by a deep, well defined and accu-
rate bass-line.
The RA-1062 includes a MM phono stage with
inputs for Tuner, Tape 1 and 2, CD, and Aux. A 12
volt trigger, IR remote input, speakers A & B
selec-
tor, headphone output, balance control and con-tour
switch round out the features of this superbly
capable integrated amplifier.
Extraordinary sound quality, remarkable flexibility, and unusual convenience highlight the RA-1070
Integrated Amplifier.
Substantial power (100 watts RMS x 2) and a
damping factor of 400 assure precise control of
the most demanding loudspeakers. The high capa-
city power supply features a Rotel-built oversi-
zed toroidal transformer and British-made BHC slit
foil capacitors for exceptionally fast response to
the demanding peaks found in todays sources.
The RA-1070 allows connection of up to eight sour-
ce components including a high quality MM phono
input, five additional line level inputs and two inde-
pendent tape monitor circuits.
It also features discrete On/Off codes, 12 volt
triggers, an RS-232 interface, two preamplifier out-
puts, speaker switching and a headphone jack
along with system remote control.
RT-1080 Tuner RCD-1072 High Resolution CD Player RA-1062 Stereo Integrated Amplifier RA-1070 Integrated Amplifier
RT-1080
RCD-1072
RA-1062 RA-1070
Model
FM tuner
Usable Sensitivity:
50dB Quieting Sensitivity:
Signal to Noise Ratio
(at 65 dBf):
Harmonic Distortion
(at 65 dBf):
Frequency Response:
Capture Ratio:
Alternate Channel Selectivity:
Spurious Response Ratio:
Image Rejection Ratio:
IF Rejection Ratio:
AM Suppression Ratio:
Stereo Separation
(100Hz/1 kHz/10 kHz):
Output level:
Antenna Input:
AM Tuner
Usable Sensitivity:
Selectivity:
Harmonic Distortion:
Image Rejection Ratio:
Signal to Noise Ratio:
Output level:
Antenna Input:
General
Power Consumption:
Power Requirements (AC):
Weight:
Dimensions (W x H x D):RT-1080
12.2 dBf
20.2 dBf (mono)
45.3 dBf (stereo)
75 dBf (mono)
72 dBf (stereo)
0.2% (mono)
0.3% (stereo)
10 Hz-15 kHz, ± 3 dB
2.0 dB
47 dB (± 400 kHz)
90 dB
80 dB
80 dB
55 dB
40 dB/45 dB/35 dB
1.2V
75 ohms unbalanced
300 µV/m
25 dB
0.5%
45 dB
48 dB
165 mV
Loop Antenna
10 watts
230 volts, 50 Hz (European version)
115 volts, 60 Hz (USA version)
4.7 Kg / 10.4 lbs
430 x 92 x 340 mm
17¹/-‚ˆ x 3-µ/-‚ˆ x 13¹/-‚ˆ Model
Total Harmonic Distortion
+ Noise
Intermodulation Distortion
Frequency Response
(± 0.5 dB)
Channel Balance
Phase Linearity
Channel Separation
Signal to Noise Ratio
Dynamic Range
Digital to Analogue
Converters
Speed Accuracy,
Wow & Flutter
Output Impedance
Digital Output
Load Impedance
Power Requirements USA Version
European Version
Power Consumption
Dimensions (W, H, D)
Front Panel Height
(for rack mount)
Weight (net) RCD-1072
0.0045% @ 1kHz
0.0045% @ 1kHz
20-20kHz
± 0.5 dB
0.5 degree
> 98 dB @ 1kHz
> 100dB
> 96 dB
18 bit equivalent,
multi-level Delta-Sigma
DAC with 8x oversampling
digital filter and HDCD
Quartz Crystal Precision
100 Ohms
0.5 Volt, Peak to Peak
75 Ohms
AC 115V, 60 Hz
AC 230V, 50 Hz
20 Watts
17¹/-‚ˆ
x 3-µ/-‚ˆ x 13¹/-‚ˆ
433 x 92 x 337mm
3 5/32, 80 mm
5.8 kg / 12.8 lbs Model
Continuous Power Output
Total Harmonic Distortion
(20Hz-20kHz)
Intermodulation Distortion
(60 Hz : 7 kHz, 4:1)
Frequency Response
Phono Input
Line Level Inputs
Damping Factor
(20-20,000 Hz, 8 ohms)
Line Input Sensitivity /
Impedance
Tone Control Bass
Treble
Line Input Overload
Phono (MM) Sensitivity /
Impedance
Input (Phono) Overload
Preamplifier Output /
Impedance
Signal to Noise Ratio
(IHF A weighted)
Power Requirements USA:
EC:
Power Consumption
Dimensions (W x H x D)
Front Panel Height
Weight (net) RA-1062
60 watts/channel
(20-20 kHz, < 0.03%, 8 ohms)
< 0.03% at rated power,
1/2 power, or 1 watt
< 0.03% at rated power,
1/2 power or 1 watt
20Hz-15kHz, ±0.2dB
10Hz-100kHz, +1, -“3dB
150
160 mV / 24 kOhms
+ 3dB or + 4dB at 100 Hz
+3dB at 10kHz
5 V
2.4mV /47 kohms
170 mV
1V / 470 ohms
>95 dB
115 Volts, 60 Hz
230 Volts, 50 Hz
300 Watts
433 x 92 x 334mm
17¹/-‚ˆ
x 3-µ/-‚ˆ x 13¹/-‚ˆ
80mm / 3 3/16
7.8 kg / 17.2 lbs Model
Watts/Channel
all channels driven,
unbridged, 8 ohm load
20 to 20kHz, 0.03% THD
THD (20-20,000Hz) cont. rated pow
er
one-half rated power
one watt per channel
IM Distortion (rated power)
Damping Factor (8 ohms)
Input Sens. / Impedance Phono (MM)
Line level inputs
Frequency Response Line Level Input
Phono input
Tone Control Bass
Treble
S/N Ratio (IHF A Network) Phono (MM)
Line level inputs
Power Consumption
Dimensions (W x H x D)
Front Panel Height
Weight (net) RA-1070
100 watts/ch
0.03%, max
0.03%, max
0.03%, max
0.05%, max
400
1.2mV / 68 kohms
150 mV / 33 kohms
4-100kHz (+/- 3db)
20-20kHz (+/- 0.5dB)
+ 3dB or + 4dB at 100Hz
+3dB at 10kHz
70 dB
102 dB
400 watts
433 x 121 x 334mm
17¹/-‚ˆ
x 4³/-‚„ x 13¹/-‚ˆ"
109 mm, 4.3"
9.1 Kg / 20 lbs
