ROLAND SH 1

Page 2

SPECIFICATIONS JUL 20 1978 SH~1

SPECIFICATIONS
\

IICEYBOAHD..........32 keys, 2-1/2 Octaves IPORTAMENTO (0-2.Ssec) l,
IVCO (Voltage Controlled Oscillator) IVOLUME

Modulator

Autobend Depth ITRANSPOSE SWITCH (L/M/H)

Autobend Time (8msec-360msec)

vco Range (32', 16', 8, 4', 2') IBLZNDER o 0

Waveform (/4 ,FIJ ,H_J) Bender Lever (-35 - +35)

Pulsewidth Modulation (5%~50%) . Bender Sensitivity (V00, VCF)

PWM Mode Switch (ENV-l/Manual/LFO)
IPOWER SWITCH

ISUB osc (silo-oscillator) Power Indicator

1 OCT DOWN FL] /2 OCT DOWN W/Z OCT
DOWN FLJ ICONNECTION JACKS
Output Jack

INOISE GENERATOR Output Level Switch (L/M/II)

White/Pink Selector (standard. -.OdBm/-8dBm/+4dBm)
Phones Jack (8Q, stereo)

IAUDIO MIXlflt , Phones Output Level Switch
VCO/SUB OSC/NOISE/EXT SIG (I:-3oom/M=-23om/n=-18m) w
Overload Indicator (EXT SIG) External Signal Jack

External Signal Level Switch (L/M/H)

IHPF (High Pass Filter) (standard 0dBm/-20dBm/-40dBm)
Cutoff Frequency Control (25Hz-5Kflz) External Control Voltage Input Jack

(lV/oct)

IVCF (Voltage Controlled Filter) External Gate Voltage Input Jack
Cutoff Frequency Control (SHz-ZOKHZ) (0N with +7.5V or over) 5
Resonance (Min-Self Oscillation) Keyboard Control Voltage Output Jack
ENV-l Polarity Switch (/\/\/) (Fl=l.4l7V, 03:4.000V, lV/oct) J
PNV-l Control Keyboard Gate Output Jack '-
MOD Control ~ (OFF - 0v, 0N - +14V)

KYBD Control
EXT SIG ENV FOL'R Control IGENEHAL
Power Consumption ................. 10W

IVCA (Voltage Controlled Amplifier) Dimensions .......... 610(W) x 370(1)) x
Hold Control 135(H)mm
Envelope Switch (ENv-l/ENV-z) 24(w) x 14.6(D) x 5.3(H)in

Weight... ....... ......6.4kg, l4.l-lbs )
IENVELOPE GENERATOR Accessory........2.5m connection cord '
ENV-l
Attack Time (l.5msec-2.5sec)
Decay Time (1.5msec-85ec)
Sustain level (0-100%)
Release Time (1.5msec-83ec)
Gate Trigger Selector Switch
(Gate+Trj g/Gate/LFO)
ENV-2
Attack Time (1.5msec-35ec)
Release Time (1.5msec-8sec)
Gate Selector Switch (Gate/130)
IMODULATOR
Modulation Mode Switch (Rundom/Fl_L/\J)
Rate (0.2Hz-25Hz)
Delay Time (O-BSec)
Hate Indicator
9
IKYBD/EXT CV GATE SWITCH -*

ITUNING (i700 cents)

1 @Roland
