Page 1
2
IMPORTANT NOTES
European Union Directives
Quad equipment is designed to comply with the legal provisions of EU Dir\
ectives
89/336/EC and 72/23/EEC. The standards which have been applied were those in
force at the time of the introduction of the product.
The product bears the CE mark:
Compliance cannot guarantee perfect performance. In the very rare circum\
stance
that you experience problems you should first try to locate and remedy t\
he origin of
any disturbance. A further option is to relocate the Quad equipment in order to
reduce the interference. Your dealer should be able to provide assistance if the
problem persists.
FCC Rule 15 Class B
This equipment has been tested and complies with the limits for a Class \
B device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential inst\
allation. This
equipment generates, uses and can radiate radio frequency energy and, if\
not
installed and used in accordance with the instructions, may cause harmfu\
l
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipm\
ent does cause
interference to radio or television reception, which can be determined b\
y turning the
equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
- Re orient or relocate the receiving antenna
Increase the separation between the equipment and the receiver
Connect the equipment into an outlet on a mains circuit different to thatto which the receiver is attached
Consult the dealer or an experienced radio/TV technician for help
This Class B apparatus meets all the requirements of the Canadian Interf\
erence
Causing Equipment Regulations.
Information to the user
Alteration or modifications carried out without appropriate authorisatio\
n may
invalidate the users right to operate the equipment.
It is always good practice to switch off equipment before connecting or disconnecting
signal leads. This will prevent unpleasant and loud noises coming from the
loudspeakers and avoid the risk of damage to equipment.
This equipment is double insulated and does not need a safety earth. It\
is
important, though, that any equipment connected to it is earthed accordi\
ng to the
manufacturers instructions. This becomes more important as the number of units
which are connected together increases.
Noise Pollution
Please be aware that very high sound pressure levels can cause permanent\
damage to your hearing and also severe annoyance to neighbours.
Page 2
3 INTRODUCTION
The Quad ESL loudspeaker is a full range electrostatic loudspeaker doublet. It
consists of a very light electrically polarised diaphragm suspended between two sets
of concentric annular electrodes. Signal is fed to the electrodes via sequential delay
lines causing the diaphragm to move and the motion of the diaphragm produces a
sound pressure pattern which is an exact replica of that from an ideal source placed
some 30cm behind the plane of the loudspeaker diaphragm.
WARNING: The Quad ESL loudspeaker has very high internal voltages. No
attempt should be made to remove the protective grilles or the baseplate.
Amplifiers which are not short circuit protected may be damaged by the
protection circuits in this loudspeaker and should not be used with the Quad
ESL.
PACKING LIST AND UNPACKING THE EQUIPMENT
The packaging contains the following items:
The Quad ESL loudspeaker
AC power lead 3m with 13A 3 pin plug (3A fuse), QUKES23
(UK only)
Instruction Manual
Warranty Registration Form
One set of packing materials comprising:
One set of packing pieces
One cardboard carton
One polythene protective bag
Consult the dealer from whom you purchased the equipment if any of these items is
not present.
The Quad ESL loudspeaker is completely assembled. To remove it from the packing,
spread out the flaps from the open end of the cardboard carton and then invert the
complete pack on to the floor, taking care not to let the contents slide out. Lift off the
cardboard carton.
Please retain the packing materials for future use or return them to your dealer. If
you decide not to keep the packing, please dispose of it sensibly. The paper and
plastics components are recoverable and may be taken to an appropriate recovery
service.
Please retain the user manual and the information concerning the date and place of
purchase of this equipment for future reference.
Page 10
IAG House
Sovereign Court
Ermine Business Park
Huntingdon
Cambs
PE29 6XU
England
Telephone: +44 (0) 1480 447700
Facsimile: +44 (0) 1480 431767
email: info@quad-hifi.co.uk
website: www.quad-hifi.co.uk
