Page 1
Precaution:
1.To prevent short-circuiting of the electrical system and cause serious
damage to the unit or the vehicle,you are advised to follow the instructions
carefully.
2.Should there be requirement to replace blown fuse,do remember to
disconnect all power supply and switched off the unit before replacing it with
a new one.Use only correct rating fuse to avoid damage the unit.
3.During operation,if there is symptom of over-heating or system mal-function,
do switch off the unit and consult your dealer immediately. Please do not
attempt to open up the unit since there is no serviceable parts inside.
4.Do not drop the LCD display panel of subject it to direct impact.
5.Should the LCD panel is broken,do avoid all human contact to the broken
glasses or fluid leaked out from the enclosure.If come into contact ,do flush
and clean affected areas with plenty of water. Seek medical attention
immediately.
6.Do not use any chemical solvent, cleaning agent or corrosive detergent to
clean away dirt on the surface of the screen.By doing so,you may cause
irreversible damage to the surface of the TFT screen.To clean off dirt or finger
prints,we recommend the use of a soft damp lens cleaning cloth.
7.Do not drop the monitor or hit it with hard object.It may cause permanent damage
to the LCD panel or the back light element.
8.When operating the display unit,avoid touching or pressing the LCD glass panel.
Excessive force may cause irreparable damage to the LCD screen.
9.Ensure no metal or foreign materials are dropped in between the display screen
and enclosure. Obstacles may impact smooth running of the tray and may cause
electrical shocks.
Page 2
PLVWR7200FPannel
A.domelight On/Off B.Power On/Off
C.Brightness- D.Brightness +
E.Contrast - F.Contast +
G.earphone jackRemote controlREMABCDEFGSYS
L/P
U/D
AV
SELSELL/PU/DAVPower On/Off the monitor
Brightness negative adjustment
Brightness positive adjustment
Contrast negative adjustment
Contrast positive adjustment
Saturation negative adjustment
Saturation positive adjustment
Negative adjustmentActive the OSD menu and shows
VOLUME-CONTRAST-BRIGHTNESS-SATURATION-HUE
Positive adjustmentChange image left/right
Change image up/down
Switch between V1 and V2
