Page 1
1
1. Table of Contents------------------------------------------------------ 1
2. Warning ---------------------------------------------------------------- 1
3. Usage Notice ---------------------------------------------------------- 2
4. Package ---------------------------------------------------------------- 3
5. Function Descriptions ---------------------------------
--------------- -4
6. ------------------------------------------------- 4
7. ----------------------------------------- 5
8. --------------------------------------------- 6
9. ---------------------------------------------- 7
10. Closing Monitor ------------------------------------------------------- 7
11. OSD Menus in A/V Source --------------------------------------------8
12. Remote Control----------------- ---------------------------------------9
13. Appendix--------------- ------------------------------------------------9
14. Specifications ------------------------------------------------------- 10
15. TV TUNER BOX -----------------------------------------------------11
16. Remote Control Function --------------------------------------------11
17. Tuner Intstallation and Electrical Connections --------------------12
18. Installation ----------------------------------------------------------- 12
19. Specifications --------------------------------------------------------16Start Your Installation
Setting Up The Dome Lamps
Installation Your Monitor
Operating the Monitor---
Table of Contents
WARNING
This unit is not intended for installation in the front Driver / Passenger Compartment
where it may be seen by the Driver. Installation of this unit in any portion of the vehicle
which could impair or distract the Driver is improper and dangerous and
assumesNo liability what so ever for failure to follow the proper installation of this
product.
To reduce the risk of electric shock, please do not expose this unit to rain, moisture or
open the unit. Dangerous high voltages are present inside the unit.
Our warranty could be voided if you make changes or modifications not expressly
approved by
Page 2
Usage Notice
Follow all warnings, precautions and maintenance as
recommended in this user's manual to maximize the life of
your LCD monitor
To avoid the damage of the LCD monitor and risk of
electronic shock, do not allow the LCD monitor to get wet.
If the monitor gets wet, turn off the power, unplug the
power cord and send the LCD monitor to your local dealer
or our service cen-ter as soon as possible.
Use a regular power specification of DC 12V . Do not use
any other power supply with different voltage.
Do not place objects on or suspend them with the power
cord.
This will damage the power cord.
Do not tangle or twist the power cord . And do not expose it
to any heated object.
Do not try to repair the power cord when it is damaged or
broken, change a new one immediately.
Avoid dropping any metal objects or inflammable liquids
into the LCD monitor from ventilation slots.
Do not attempt to open or disassemble the LCD monitor
yourself as this may cause electronic shock.
When there is smoke or peculiar smell in use, unplug the
power cord immediately and send it to your local dealer or
our service center.
When there is damage to the LCD monitor casing, send it to
your local dealer or our service center.
Do not use this LCD monitor in areas susceptible to
excessive dust, dirt, and humid.
Do not install the LCD monitor in areas that are exposed to
direct sunlight, extreme heat, and extreme cold
environment.
Do not expose the LCD monitor to rain or moisture.
2
