Page 1
PannelPOWERSEL+-Remark:MODE,UP/DOWN,VOLUME,MUTE are not available
for this model.Contents and specifications can be subjected to change without prior notice.Accessories
Remote control
Cautions
Never connect the car adaptor to cigarette lighters for
such as trucks or buses which use 24V DC power.
Do not expose the monitor to high humidity,dust,steam,
oily smoke,direct sunlight etc.
For your safety, turn power OFF when not in use and
unplug the adaptor.
Never attempt your own maintenance.Consult your TV
dealer or the company.
Avoid dropping and strong impact.
For your safety,the driver should not watch the Monitor
or operate the controls while driving.
WARNING:
DO NOT WATCH MONITOR WHILE VEHICLE IN MOTION.
IT CAN BE HAZARDOUS.
Screen Size: 10inch 4:3TFT
System: PAL/NTSC
Power source/Consumption: DC12V+/-20%,1250mA
Video Input: Composition Video signal
Storage Temperature: -10 ~ +85
Display Method : Color LCD
Resolution(HxV): 1024(H) x 768(V)
Back light: Cold Cathode Filament Tube
Monitor dimension: 286x280x35mm
Specifications
MD
L/R
U/D
AV
TFT-LCD
MONITOR REMOTEPower on /offColor +Color -Contrast + Volume +Volume -Brightness+MuteModeUp/downLeft/rightVideo1 /video21.Sensor for remote 2. Adjustment (-)
3.SEL 4.Adjustment (+)5.POWER 1 2 3 4 5
1xRemote control
1xinstruction manual 1xMetal Bracket Brightness-Contrast -
