1.Never attempt your own maintenance.If something appears strange,
please turn the monitor off and consult the dealer or the company.The
monitor is composed of many delicate electronic components that can
be damaged or broken if you open the it or attempt to modify it.
2.Do not expose the device to high humidity,dust,steam,oily smoke,
direct sunlight etc.3.Do not use thinners or other chemical cleaners.Wipe the it off with a
soft cloth if it gets dirty.
4.Do not leave the device in excessively hot or cold places.
Permissible storage temperatures are within the range of -25 to +60.
Permissible operation temperatures are within the range of 0 to +40.
5.Only use specified adaptors and power sources.
6.For your safety,turn power off when not in use and unplug the adaptor.
7.Avoid dropping and strong impact.Caution:For your safety,driver shouldn`t watch or operate the controls
while driving.
Note that watching and operating it while driving is prohibited by law
in some countries.
Special caution:It doesn`t mean the TV is broken with bright or dark
colour dots on the LCD,as it is sometimes inevitable.Never connect the car adaptor to cigarette lighters for
such as trucks or buses which use 24V DC power.
Always be sure to use the fittings with the monitor, using
any other AC adaptor or car adaptor can cause damage
to TV.
If you do not use the it for a long time,be sure to discon-
necting the car adaptor from the cigarette lighter or the
AC adaptor from the wall outlet.CAUTIONSA)CAUTIONSThank you for the purchase of this TFT monitor. Before operating the unit,
please read this manual thoroughly and retain it for future reference.
Page 2
B)FRONT PANELPANELIMAGE UP/DOWNIMAGE LEFT/RIGHTB)WIRINGRED:DC 12V
BLACK:GNDYELLOW:VIDEO INPUTFUSESPECIFICATIONSScreen size: 7 inch
Display method: TFT Active matrix
System: PAL & NTSC
Aspect ratio: 16:9Power input: 12V DC
Power consumption: About 7W
Pixel: 1440X234Dimension: 23X13.5X2.7mmWeight: 450gNote:Although the effective pixels for the liquid crystal is given as 99.98%
or more,0.02% of pixels may not light or may light incorrectly.It is a very
common phenomenon in active matrix display technology,do not indicate
fault or broken of the unit.Contents and specifications can be subject to change without prior notice.The monitor will be automatically on if there is signal input.
