Select
Open button
AV1/AV2
Remote receiver
Analog decrease
Analog increasePower switch
Menu
Type:TFT LCD Video Monitor
Built-in Clock
Display Size:6.5"
Display Format:4:3
Power: About 7W
Operation Temperature:0 60
Power supply: DC 11V-14V
System: NTSC
Resolution:1048x234
Overall Dimension:190(L)x182(W)x50(H)mm
Weight:About 1900g
09 28
Adjust minuter Adjust hour
Control Panel
Performance Parameter
White to video 2
Yellow to video 1 Green to manual brake
Yellow to ACC(+12V)
Red to battery +12V Black to grounding
Power switch
Precast picture
U/D and L/R Image Reversion
Remote Control
Power Cord
P. P
AV
MENU
Mute
V1V2 MENU
Clock
Video cord
Power cord
Video cord
Fuse 2A
GreenYellow Black RedYellow White
Method Of Wiring
