Table of ContentsAbout the liquid crystal display (LCD) panel
Troubleshooting guide
Precautions
Control & Layout for monitor / wireless remote
Accessories
Connection diagram
Replacing the remote control battery
Installing headrest with shroud
Installing sun-visor with shroud
installing of headrest case
Function setting
Specifications 123345667-89-101112-2223
Page 2
2About the liquid crystal display (LCD) panel
1. Do not press on the LCD panel on the monitor unit as doing so can distort the picture or cause a
malfunction, the picture may become unclear, or the LCD panel may be damaged.
2. Notes on cleaning
-clean the LCD panel with a slightly damp soft cloth.
- do not use solvents such benzine, thinner, commercially available cleaners or antistatic spray.
oooo
3. Do not use this unit temperatures under 5C (41F) or over 45C (113F).
4. If your car was parked in a clod or hot place, the picture may not be clear. The monitor isnotdamaged.
The picture will become clear after temperature in your car becomes normal.
5.Some stationary blue or red dots may appear on the monitor.These are called bright spots,and happen
with anyLCD.The LCD panel is highly sophisticated, and more then 99.99% ofthe segments used in
the panel are flawless.However, there is a possibility that less than 0.01% of the segments are defective
and maynot light up properly. However, these segments will not interfere with your viewing.Warning
To Prevent fire or shock hazard, do not expose the unit to
rain or moisture.This symbol is intended to alert the user to
thepresence of uninsulated DANGEROUS
VOLTAGE within the products encloseure
that may be of sufficient magnitude to
constitute a risk of electric shock to persons.This symbol is intended to alert the user to
the presence of important operating and
maintenance(servicing) instructions in the
literature accompanying the appliance.!!CAUTION!!
RISK OF ELECTRIC SHOCK
DO NOT OPENCaution: To reduce th risk of electric shock
Do not remove cover (or Back)
No user-serviceable parts inside
Refer servicing to qualified service personnelNo picture, no soundThe power cord or battery has been disconnected.
The fuse has blown.
Press power on.Good picture, but no soundDolled lines or stripesThis maybe caused by local interference such as car
engine or motorcycle.No picture, or no sound when you
connect the optional equipmentThe cord has been disconnected. Connect the cord
securely.
Press power on.No response when pressing the buttons on
the wireless remoteThe wireless remote batteries may be exhausted.Press the volume increase button on the wireless
remote, or on the monitor.
Press the mute button from the wireless remote.
(TIP: refer to page 4 for the control & layout)ProblemCause/solutionTroubleshooting guideThe following checklist will help you solve problems you may encounter with your unit.
Before going through the checklist below, check the connection and operating.
if you can not solve the problem with follows guide, please contact your nearest dealer.
