Page 1
Thank you for the purchase of this Super slim design 7 inch Color TFT-LCD
monitor.Before operating the unit,please read this manual thoroughly and
keep it for future reference.
PANEL
PLVHR70
SHARP TFT-LCD
12345 6
1.Power:Power on/off
Press this button to turn on the monitor,press again to turn the monitor
off.
2.Brightness/co lor/contrast negative adjust ment
To adjust brightness,co lor or contrast negatively.
3.SEL:to activate the menu and select brightness,color or contrast.
4.Brightness/co lor/contrast posit ive adjust ment
To adjust brightness,co lor or contrast posit ively.
5.AV:to change video signal sources between V1/V2.
6.Remote control receiver
The device has the function of Picture-Flip,it allows you to rotate the screen
180 degrees and have the picture automatically flip so you can view the
picture upside-down!So you can mount the monitor up side-down in a car.
NOTE:Although the effective pixels for the liquid crystal is given as 99.98% or
more,0.02% of pixels
may not light or may light incorrectly.It is a very commo n pheno menon in act ive
matrix display
technology,do not indicate fault or broken of the unit.
Contents and specifications can be subject to change without prior notice.
Page 2
REMOTE CONTROL
P o we r : P ow er on /of f
B r i gh t ne ss a dj u st m en t
C o l or ad j ust m ent
C o nt r a st adj us t m ent
P P : S e l e ct am ong t h e pr es et di s pl ay m ode
( ME M O RY- S TA N D A R D - S O FT-V I V I D - LI G H T)
V 1 / V 2: C ha nge b et w e en V 1 an d V 2 .
SYS: Image zoom
POWER
WIRING
23mm
RE D: D C 1 2 V +
RE D: V 1 INP UT
YELLOW: V2 INPUT
BLACK: GROUND
NSTALLATION
1.STAND ALONE BRACKET
2.HEADREST BRACKET
