Pyle pltcdn 7 owners manual

Page 1

Contents 1 Thank you for purchsing this product. * Please read this owner's manual carefully before installation and operating this unit and follow up all instructions for safe connecting, operating this product. Otherwise, the unit can be damaged. * Pleas keep this manual in a handy place for future use. Contents Precaution...................................................................................2 Handling Discs ............................................................................3 Operating with the main unit........................................................4 Operating with the Remote Control.............................................5~6 Basic Opreations.......................................................................7 Radio Opration............................................................................8 Basic Opreations with Touch Keys..............................................9~10 System Settings with Touch Keys.............................................11 Radio Opration with Touch Keys................................................12 TV Opration with Touch Keys.....................................................13 DVD/CD Changer Operation with Touch Keys...........................14 Navigation Operation with Touch Keys.......................................14 Rear View Camera Operation with Touch Keys.........................15 DVD System Settings with Touch Keys......................................16 General Setup.............................................................................17 Speaker Setup............................................................................17 Audio Setup................................................................................18 Preference..................................................................................19~20 DVD Video Operation with Touch Keys.....................................21 VCD Operation with Touch Keys................................................22 Listening to CD with Touch Keys...............................................23 Listening to MP3 with Touch Keys.............................................24 Accessories................................................................................25 Installation..................................................................................26 Wire Connections.......................................................................27 Connection for AV Equipments...................................................8~29 Specifications.............................................................................30~31 Troubleshooting Guide...............................................................32

Page 2

Precautions 2 Warning Screen While the vehicle is in motion, the monitor only shows "WARNING PICTURE" to prevent trafficaccident. Stop the car in a safe location and apply the parking break to watch the picture. 1. Driving on extremely bumpy roads which cause severe vibration may cause the sound to skip. 2. When the temperature of the unit falls such as during winter, the monitor screen will become darker than usual. Normal brightness will return after using the monitor for a while. 3. This unit uses a precision mechanism. Even in the event that trouble arises, never open the case, disassemble the unit, or lubricate the rotating parts. Be sure to consult your supplier. 4. Any changes or modifications to this product not approved by the supplier could void the warranty and will violate FCC approval. WARNING
