This is the 2 pages manual for pyle plta 12 owners manual. Read or download the pdf for free.
If you want to contribute, please mail your pdfs to info@audioservicemanuals.com.
Page: 1 / 2
Extracted text from pyle plta 12 owners manual (Ocr-read)
Page 1
CONNECTION DIAGRAM CONNECTION DIAGRAM
SYSTEM FEATURES SYSTEM FEATURES
SPECIFICATIONS SPECIFICATIONS
Sound Quality/
Input Phase Switch
(0˚ - 180˚)7.5 Amp
Fuse12V(+) Battery
Remote Start/
Power Antenna
Chassis (-)
Ground
Speaker/
High Level
InputsRCA/
Low Level
InputsInput
Level
Control Crossover
Frequency
Simple Connection Plate and Interface Allows for an
Easy, Quick and Straight Forward Installation
8"/10"/12" Pyle Red Label Long Throw Woofer
Custom Designed Carpeted Enclosures w/Bass Reflex Ports
Optimized for Best Bass Response
Compact and Rugged Design
Built-In Amplified System
Adjustable Crossover Frequency Control
Input Level Control
3-Way Input Phase Switch (0
˚/90˚/180˚
)
Automatic Turn On Feature
RCA/Low Level Inputs
Speaker/High Level Inputs
Custom Triple Bar Grill Design
Woofer Size
Voice Coil
Magnet
Freq. Resp.
Dimensions
Impedance
System Watts
PLTA8 PLTBA10 PLTBA12
8"
1" High Temp
20 oz
50Hz-200Hz
9.9" x19" x13.8
Dual 2 Ohms
300 Watts
10"
1.5" High Temp
30 oz
50Hz-200Hz
12.2" x18.9" x15.8
Dual 2 Ohms
500 Watts12"
2" High Temp
40 oz
50Hz-200Hz
13.8" x18.9" x16.3
Dual 2 Ohms
600 Watts
